1648163-1
| 制造商 | |
| 描述 | Conn Housing PIN 4/24/9 POS Crimp ST Panel Mount High Power Drawer - Elcon CONN PIN MID-DRAWER 8/20/12 PCB Heavy Duty Power Connectors PIN HOUSING CONN SIZE 8 12 20 RECTANGULAR POWER CONNECTOR, PLUG, 37POS |
| 分类 |
商业参数
| 产品类别 | Heavy Duty Power Connectors | 标准包装数量 | Bulk |
| 工厂包装数量 | 30 | ||
合规参数
| RoHS | Lead free / RoHS Compliant | 海关税号 | 85366910 |
| 无铅定义 | Wave solder capable to 260°C / Wave solder capable to 240°C / Wave solder capabl | RoHS/ELV合规状态 | RoHS compliant / ELV compliant |
| 材料阻燃等级 | UL 94V-0 | ||
电气参数
| 最大额定电流 | 75 | ||
机械参数
| 颜色 | Black | 重量 | 0 |
| 包装方式 | Bulk | 触点尺寸 | 8 / 12 / 20 |
| 触头类型 | Size 8 + Size 12 + Size 20 | 外壳颜色 | Black |
| 安装类型 | Fixed | 连接器类型 | Housing for Male Pins |
| 接触镀层 | :- | 连接器样式 | Plug |
| 连接器用途 | Plug | 插入力 | Male |
| 触头材料 | :- | 壳体材料 | Thermoplastic - GF |
| 第一触头极性 | :- | 触点数 | :37 |
| 接触件端接 | :- | 位数 | 37 (24 + 13 Power) |
| 第一连接器安装类型 | :PCB | ||
产品信息
| 备注 | Contacts Not Provided | 连接器性别 | :Plug |
| 系列 | :- | 产品特性 | Guide Pin |
| 预加载 | No | 制造商全称 | Elcon |
| 产品子类型 | Connector | 抽屉总数 | Middle |
