5-102618-4

点击放大查看

5-102618-4

制造商
TE Connectivity Ltd.
描述Conn Shrouded Header HDR 12 POS 2.54mm Solder ST Thru-Hole .100 inch AMPMODU Headers CONN HEADER VERT .100 12POS 15AU TE Connectivity AMPMODU Series 2.54mm Pitch 12 Way 2 Row Straight PCB Header, Solder Termination, 3A Headers & Wire Housings SHROUDED VER DUAL 12 detent windows Conn Shrouded Header HDR 12 POS 2.54mm Solder ST Thru-Hole Product Highlights:HeaderHeader Type = ShroudedNumber of Rows = DualNumber of Positions = 12Mating Post Length = 8.08 mmSearch Keywords:board to board, AMPMODU, pcb connectors, HEADER, VERTICAL, 2ROW, 12WAY MODUTHRUDRHDRSHRD,12MODIIHDRDRSTSHRD.100CL TE Connectivity AMPMODU Mod II 系列 12路 2.54mm节距 (2排) 直 PCB 针座 , 焊接端接, 3A, 通孔 12 MODII HDR DRST SHRD .100CL
分类
连接器解决方案板对板连接器带罩排针连接器
对参数有疑问？问 AI 助手

商业参数

商标名AMPMODU产品类别Headers & Wire Housings
标准包装数量Trays工厂包装数量272

合规参数

RoHSLead free / RoHS Compliant海关税号85369010
无铅定义Wave solder capable to 240°C认证机构:CSA, UL
RoHS/ELV合规状态RoHS compliant, ELV compliant材料阻燃等级UL 94V-0

电气参数

量程（°/s）:TE - AMPMODU Mod II Series额定电压:250V
开关功能Detent Windows工作电压:250V
最大额定电流3A绝缘电阻:500Mohm

机械参数

颜色Black深度10.16 mm
间距2.54 mm高度11.18 mm
重量0.0002包装方式Tray
排间距0.100" (2.54mm)端接方式Solder
触头类型Male Pin引脚间距:2.54mm
第一连接器No第二连接器With
触点形状Square外壳颜色Black
安装类型Vertical连接器类型Shrouded
接触镀层Gold Over Nickel紧固类型Detent Lock
安装样式Through Hole排数2
封装形式4-Sided锁定特性Detent Windows
外形（宽 x 高）Standard触头材料Phosphor Bronze
壳体材料Thermoplastic总长度1.68 [0.066]
安装特性Without面板安装类型Without
主要材料InterconnectSystem尺寸/外形0.64 [.025]
端接样式Through Hole第一触头极性Pin (Male)
触点数12接触件端接:Through Hole Vertical
位数12柱体长度（配合）8.08 mm
中心触点材料2.54 x 2.54 [.100 x .100]接触长度 - 配合8.08 [0.318]
表面贴装焊盘尺寸No端子柱长度3.18 [0.125]
接触镀层厚度15µin (0.38µm)

产品信息

类型Shrouded Header连接器性别HDR
系列AMPMODU制造商全称AMP
产品子类型Header选择性装载No
加载位置数All

环境参数

温度No工作温度-55 – +105

文档与媒体

在线文档
5-102618-4

相关型号

5-534206-6

5-534206-6

te connectivity / amp
