1-640250-3
| 制造商 | TE Connectivity Ltd. |
| 描述 | Conn Housing RCP 13 POS 3.96mm Crimp ST Cable Mount MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN RECEPT 13POS W/RAMP SL-156 SL-156 Socket Housing + locking ramp 13P Headers & Wire Housings SL 156 HSG 13P Conn Housing RCP 13 POS 3.96mm Crimp ST Cable Mount Product Highlights:SL-156 HousingsNumber of Positions = 13Mating Type = ReceptacleWire-to-Board Application3.96 mm Contact Centerline SpacingSearch Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP WIRE-BOARD CONNECTOR RECEPTACLE 13POS, 3.96MM CONNECTOR,SOFTSHELL,SL-156,RECEPTACLE,13POSITION,NYLON,WHITE TE Connectivity SL-156 系列 1 行 3.97mm 节距 13 路 直 母 电缆安装 压接连接器外壳 13P SL156 HSG W/LCK RAMP NATL |
| 分类 |
商业参数
| 产品类别 | Headers & Wire Housings | 标准包装数量 | Bulk |
| 工厂包装数量 | 100 | ||
合规参数
| RoHS | Lead free / RoHS Compliant | 海关税号 | 85369010 |
| 无铅定义 | Not relevant for lead free process | RoHS/ELV合规状态 | RoHS compliant, ELV compliant |
| 材料阻燃等级 | UL 94V-0 | ||
电气参数
| 最大额定电流 | 10/Contact A | 最小供电电压 | 250VAC |
机械参数
| 颜色 | Natural | 深度 | 16.76 mm |
| 间距 | 3.96 mm | 高度 | 7.27 mm |
| 重量 | 0 | 包装方式 | Bulk |
| 遮蔽类型 | No | 出线方向 | 180° |
| 导线线规 | 16-24 AWG | 触头类型 | Female Socket |
| 第二连接器 | With | 外壳颜色 | White |
| 安装类型 | Straight | 连接器类型 | Crimp |
| 接触镀层 | :- | 紧固类型 | Locking Ramp |
| 排数 | 1 | 连接器用途 | Receptacle |
| 锁定特性 | Locking Ramp | 触头材料 | :- |
| 壳体材料 | Nylon | 总长度 | 51.49 mm |
| 安装特性 | Without | 面板安装类型 | Without |
| 端接样式 | Crimp | 第一触头极性 | Socket (Female) |
| 配接方向 | Without | 触点数 | 13 |
| 接触件端接 | Crimp | 绝缘直径 | Standard |
| 位数 | 13 | 典型触点布局 | 3.96 [0.156] |
产品信息
| 备注 | Recommended contact: Part No. 350980 and Part No. 770476 | 类型 | Housing |
| 连接器性别 | RCP | 系列 | SL-156 |
| 制造商全称 | AMP | 产品子类型 | SL-156 Housings |
| 应用细节 | Wire-to-Board | ||
环境参数
| 工作温度 | -55C to 105C | ||
