2-87589-1

点击放大查看

2-87589-1

制造商
TE Connectivity Ltd.
描述Conn Shrouded Header HDR 50 POS 2.54mm Solder ST Thru-Hole .100 inch AMPMODU Headers CONN HEADER VERT 50POS PCB TIN Headers & Wire Housings SHROUDED VER DUAL 50 detent windows .100 inch AMPMODU Headers Product Highlights:HeaderHeader Type = ShroudedNumber of Rows = DualNumber of Positions = 50Mating Post Length = 8.08 mmSearch Keywords:board to board, AMPMODU, pcb connectors, 50 MODII HDR DRST SHRD .100CL
分类
连接器解决方案板对板连接器板对板连接器
对参数有疑问？问 AI 助手

商业参数

商标名AMPMODU其他名称A26752
标准包装规格64产品类别Headers & Wire Housings
标准包装数量Trays工厂包装数量64

合规参数

RoHSContains lead / RoHS non-compliant标准编号CSA LR7189, UL E28476
材料阻燃等级UL 94 V-0

电气参数

开关功能Detent Windows连接器阻抗制动器窗口
最大额定电流3 A绝缘电阻5000 MOhms
保护额定电压（VPR）750 Vrms

机械参数

颜色Black间距2.54 mm
底座类型不带锁定类型带有
包装方式Tray壳体颜色黑色
引脚样式正方形稳定器不带
排间距0.100" (2.54mm)端接方式Solder
触头类型Male Pin第一连接器否
安装类型Through Hole连接器类型Header, Shrouded
接触镀层Bright Tin Over Nickel紧固类型Detent Lock
安装样式标准排数2
外壳材料（壳体）4- 面插入件材料磷青铜
触头材料Phosphor Bronze壳体材料Nylon
包装数量64面板安装类型通孔
端接样式Through Hole第一连接器类型带罩
第一触头极性Pin (Male)外径.64 mm [ .025 in ]
触点数50端接表面处理带有
位数50柱体长度（配合）8.08 mm
安装孔直径带有接触长度 - 配合0.318" (8.08mm)
端子柱长度3.18 mm接触镀层厚度100µin (2.54µm)
静电放电屏蔽不带外壳尺寸，连接器布局1.68 mm [ .066 in ]
第一连接器安装特征否接触件镀层 - 插柱（配合端）锡铅：亮光

产品信息

类型Shrouded Header连接器性别HDR
系列AMPMODU MOD II钥匙类型否
产品子类型Headers加载位置数All

环境参数

密封等级不带防护等级带罩
工作温度- 55 C to + 105 C结工作温度否

文档与媒体

在线文档
2-87589-1

相关型号

2-534206-5

2-534206-5

te connectivity / amp

Conn Socket Strip SKT 50 POS 2.54mm Solder ST Thru-Hole Gang of Tubes Headers & Wire Housings REC 2X25P VRT T/H 540 .100 inch AMPMODU Receptacles CONN RECEPT 50POS .100 VERT DUAL Conn Socket Strip SKT 50 POS 2.54mm Solder ST Thru-Hole Gang of Tubes Product Highlights:ReceptacleMod IINumber of Positions = 50Number of Rows = DualStandard ProfileSearch Keywords:AMPMODU, board to board, NIC, Network Interface Cards, PC Cards, MIL-C-55032, MIL-C-24519, pcb connectors, wire to board, signal, VERTIIDRCERECASY,50MODIIVRTDRCE100/115 50 MODII VRT DR CE 100/115

¥20.4000
详情
2-146762-6

2-146762-6

te connectivity / amp

Conn Socket Strip RCP 50 POS 2.54mm Solder ST Thru-Hole Gang of Tubes .100 inch AMPMODU Receptacles CONN RCPT 50POS DL VERT .100 T/H 50 MODII RCPT VERT DR

详情
2-534998-5

2-534998-5

te connectivity / amp

Conn Socket Strip RCP 50 POS 2.54mm Solder ST Thru-Hole Gang of Tubes .100 inch AMPMODU Receptacles CONN RECEPT 50POS .100 VERT DUAL Headers & Wire Housings 50P RECEPTACLE Conn Socket Strip RCP 50 POS 2.54mm Solder ST Thru-Hole Gang of Tubes Product Highlights:ReceptacleMod IVNumber of Positions = 50Number of Rows = DualLow ProfileSearch Keywords:AMPMODU, board to board, NIC, Network Interface Cards, PC Cards, MIL-C-55032, MIL-C-24519, pcb connectors, wire to board, signal, 50 MODIV VRT DR CE 100/125

¥16.1840
详情
7-102398-3

7-102398-3

te connectivity / amp

Conn IDC Connector RCP 50 POS 2.54mm IDT ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN RECEPT 50POS .100 IDC GOLD AMPMODUMTReceptacleAssembly,50Pos. AMPMODU MT Receptacle Assembly; 50 Pos.; Dual Row; IDC; 26-22AWG; .100 CL Headers & Wire Housings HSG DUAL 50P 26-22 Conn IDC Connector RCP 50 POS 2.54mm IDT ST Cable Mount Product Highlights:HousingPreloadedNumber of Positions = 50Housing Type = ReceptacleContact Type = ReceptacleSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE WIRE-BOARD CONN RECEPTACLE 50POS, 2.54MM AMPMODUMTReceptacleAssembly,50Pos.,DualRow,IDC,26-22AWG,.100CL 50 AMPMODU MT ASSY DR.100CL SN

¥43.9280
详情
2-102398-3

2-102398-3

te connectivity / amp

Conn IDC Connector RCP 50 POS 2.54mm IDT ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN RECEPT 50POS .100 IDC GOLD Headers & Wire Housings HSG DUAL 50P 26-22 Conn IDC Connector RCP 50 POS 2.54mm IDT ST Cable Mount Product Highlights:Receptacle AssemblyWire Termination Type = Insulation Displacement Crimp (IDC)Number of Positions = 50Number of Rows = DualTerminate To WireSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE 50 AMPMODU MT ASSY DR .100CL

¥62.4988
详情
2-86177-1

2-86177-1

te connectivity / amp

Conn Housing RCP 50 POS 2.54mm Crimp ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN RCPT HSNG 50POS DL CRIMP Headers & Wire Housings 50 MODIV HSG COMP DR .100CL Conn Housing RCP 50 POS 2.54mm Crimp ST Cable Mount Product Highlights:Receptacle HousingWire Termination Type = CrimpNumber of Positions = 50Housing Type = ReceptacleNumber of Rows = DualSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE 50 MODIV HSG COMP DR .100CL

¥27.4720
详情
4-87631-1

4-87631-1

te connectivity / amp

Conn Housing RCP 50 POS 2.54mm Crimp ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN HOUSING 50POS .100 POL DUAL Headers & Wire Housings 50 HSG COMP DR .1POL Conn Housing RCP 50 POS 2.54mm Crimp ST Cable Mount Product Highlights:Receptacle HousingWire Termination Type = CrimpNumber of Positions = 50Housing Type = ReceptacleNumber of Rows = DualSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE WIRE-BOARD CONNECTOR RECEPTACLE 50POS, 2.54MM 50 MODIV HSG COMP DR .100 POL

¥13.3960
详情
7-102393-3

7-102393-3

te connectivity / amp

Conn IDC Connector RCP 50 POS 2.54mm IDT ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN RECEPT 50POS .100 IDC GOLD Headers & Wire Housings HSG DUAL 50P 30-26 .100 AMPMODU Headers, Housings & Contacts Product Highlights:HousingPreloadedNumber of Positions = 50Housing Type = ReceptacleContact Type = ReceptacleSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE 50 AMPMODU MT ASSY DR.100CL SN

¥42.3300
详情
2-147424-5

2-147424-5

te connectivity / amp

Conn Socket Strip RCP 50 POS 2.54mm Solder ST Thru-Hole Gang of Tubes .100 inch AMPMODU Receptacles CONN RCPT 50POS VERT .100 T/H Headers & Wire Housings 50 MODII VRT DR CE .100 X .100 Conn Socket Strip SKT 50 POS 2.54mm Solder ST Thru-Hole Gang of Tubes Conn Socket Strip SKT 50 POS 2.54mm Solder ST Thru-Hole Gang of Tubes Product Highlights:ReceptacleMod IINumber of Positions = 50Number of Rows = DualStandard ProfileSearch Keywords:AMPMODU, board to board, NIC, Network Interface Cards, PC Cards, MIL-C-55032, MIL-C-24519, pcb connectors, wire to board, signal, 50 MODII VRT DR CE .100 X .100

¥26.5200
详情
7-102448-3

7-102448-3

te connectivity / amp

Conn IDC Connector RCP 50 POS 2.54mm IDT ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN RECEPT 50POS .100 IDC GOLD Headers & Wire Housings HSG DUAL 50P 22-20 Conn IDC Connector RCP 50 POS 2.54mm IDT ST Cable Mount Product Highlights:HousingPreloadedNumber of Positions = 50Housing Type = ReceptacleContact Type = ReceptacleSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE WIRE-BOARD CONNECTOR RECEPTACLE 50POS, 2 Receptacle;MT(IDC);26to22AWG;InsulationDisplacementCrimp(IDC);50Pos. 50 AMPMODU MT ASSY DR.100CL SN

¥59.0920
详情
4-87456-0

4-87456-0

te connectivity / amp

Conn Housing RCP 50 POS 2.54mm Crimp ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN HOUSING 50POS .100 DUAL Housing,Connector,Crimp-Snap,Dual Headers & Wire Housings HSG 2X25C F/H Conn Housing RCP 50 POS 2.54mm Crimp ST Cable Mount Product Highlights:Receptacle HousingWire Termination Type = CrimpNumber of Positions = 50Housing Type = ReceptacleNumber of Rows = DualSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE Housing,Connector;Crimp-Snap;Dual;50;250VAC;3A;750V 50 MODIV HSG DR MRKD .100CL

¥10.8120
详情
2-535598-1

2-535598-1

te connectivity / amp

Conn Socket Strip SKT 50 POS 2.54mm Solder ST Thru-Hole .100 inch AMPMODU Receptacles CONN RCPT 50POS .100 DUAL T/H AU Headers & Wire Housings 50 MODIV VRT DR CE RCPT ASSY 50 MODIV VRT DR CE RCPT ASSY 50 MODIV VRT DR CE RCPT ASSY Search Keywords:AMPMODU, board to board, NIC, Network Interface Cards, PC Cards, MIL-C-55032, MIL-C-24519, pcb connectors, wire to board, signal,

¥14.1481
详情
2-102448-3

2-102448-3

te connectivity / amp

Conn IDC Connector RCP 50 POS 2.54mm IDT ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN RECEPT 50POS .100 IDC GOLD Headers & Wire Housings HSG DUAL 50P 22-20 50 AMPMODU MT ASSY DR .100CL

¥76.5000
详情
7-534998-5

7-534998-5

te connectivity / amp

Conn Socket Strip RCP 50 POS 2.54mm Solder ST Thru-Hole Gang of Tubes .100 inch AMPMODU Receptacles CONN RECEPT 50POS .100 VERT DUAL Headers & Wire Housings REC 2X25P VRT T/H Conn Socket Strip RCP 50 POS 2.54mm Solder ST Thru-Hole Gang of Tubes Product Highlights:ReceptacleMod IVNumber of Positions = 50Number of Rows = DualLow ProfileSearch Keywords:AMPMODU, board to board, NIC, Network Interface Cards, PC Cards, MIL-C-55032, MIL-C-24519, pcb connectors, wire to board, signal, BOARD-BOARD CONNECTOR RECEPTACLE, 50WAY, 2ROW 50 MODIV VRT DR CE 100/125

¥23.9360
详情
3-87456-9

3-87456-9

te connectivity / amp

Conn Housing RCP 50 POS 2.54mm Crimp ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN HOUSING 50POS .100 DUAL ROW Headers & Wire Housings 50 MODIV HSG COMP DR Conn Housing RCP 50 POS 2.54mm Crimp ST Cable Mount Product Highlights:HousingNot PreloadedNumber of Positions = 50Housing Type = ReceptacleNumber of Rows = DualSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE WIRE-BOARD CONNECTOR RECEPTACLE 50POS, 2.54MM 50 MODIV HSG COMP DR .100CL

¥11.8320
详情
4-87631-2

4-87631-2

te connectivity / amp

Conn Housing RCP 50 POS 2.54mm Crimp ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN HOUSING 50POS .100 POL DUAL Headers & Wire Housings HSG 2X25C F/H POL Conn Housing RCP 50 POS 2.54mm Crimp ST Cable Mount Product Highlights:Receptacle HousingWire Termination Type = CrimpNumber of Positions = 50Housing Type = ReceptacleNumber of Rows = DualSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE Housing,Connector;Crimp-Snap;Dual;50;250VAC;3A;750V 50 MODIV HSG DR MRKD .100 POL

¥10.6080
详情
7-534206-5

7-534206-5

te connectivity / amp

Conn Socket Strip SKT 50 POS 2.54mm Solder ST Thru-Hole Gang of Tubes .100 inch AMPMODU Receptacles CONN RECEPT 50POS .100 VERT DUAL Headers & Wire Housings REC 2X25P VRT T/H Conn Socket Strip SKT 50 POS 2.54mm Solder ST Thru-Hole Gang of Tubes Product Highlights:ReceptacleMod IINumber of Positions = 50Number of Rows = DualStandard ProfileSearch Keywords:AMPMODU, board to board, NIC, Network Interface Cards, PC Cards, MIL-C-55032, MIL-C-24519, pcb connectors, wire to board, signal, BOARD-BOARD CONNECTOR RECEPTACLE, 50WAY, 2ROW VERTIIDRCERECASY,50MODIIVRTDRCE100/115 TE Connectivity AMPMODU Mod II 系列 2行 50路 直 2.54mm节距 通孔 印刷电路板插座, 板对板 50 MODII VRT DR CE 100/115

¥21.2840
详情
1324039
