点击放大查看
14-56-2021
| 制造商 | Molex, LLC |
| 描述 | CONN IDC 2POS .100 GOLD 24AWG Headers & Wire Housings CGrid SL IDT Opt A 15 SAu 2Ckt |
| 分类 |
商业参数
| 商标名 | C-Grid, SL | 零件号别名 | 0014562021 704000526 |
| 产品类别 | Headers & Wire Housings | 标准包装数量 | 1 |
| 工厂包装数量 | 3120 | ||
合规参数
| RoHS | RoHS Compliant | ||
电气参数
| 额定电压 | 250 V | 最大额定电流 | 3 A |
机械参数
| 颜色 | Black | 间距 | 0.100" (2.54mm) |
| 包装方式 | Tube | 导线类型 | Discrete or Ribbon Cable |
| 导线线规 | 24 AWG | 触头类型 | Female Socket |
| 安装类型 | Free Hanging (In-Line) | 连接器类型 | Receptacle |
| 接触镀层 | Gold | 安装样式 | Cable |
| 排数 | 1 | 触头材料 | Phosphor Bronze |
| 壳体材料 | Polyester Alloy | 电缆端接方式 | IDC |
| 端接样式 | IDC | 第一触头极性 | Socket (Female) |
| 触点数 | 2 | 位数 | 2 |
| 接触镀层厚度 | 15µin (0.38µm) | ||
产品信息
| 系列 | 70400 | 产品特性 | Closed End |
| 产品子类型 | Receptacles / Sockets - Housings | ||
