点击放大查看

SVH-41T-P1.1

制造商	JST Mfg. Co., Ltd.
描述	CONN TERM CRIMP VH 16-20AWG TIN VH 3.96MM CONTACT 20-16 AWG REELED Contact; female; 0.5÷1.25mm2; VH; crimped; 3.96mm JST SVH 系列母压接接线端子, 压接, 镀锡触点
分类	连接器解决方案接触件接触件（通用）

对参数有疑问？问 AI 助手

商业参数

其他名称

455-1319-1

标准包装数量

3,500

合规参数

RoHS

Lead free / RoHS Compliant

电气参数

接触电阻

10mΩ

机械参数

重量	0.44 g	包装方式	Tape & Reel (TR)
导线线规	16-20 AWG	端接方式	Crimp
柱间距	3.96mm	安装类型	crimped
插针或插孔	Socket	电缆直径	1.25mm²
连接器类型	female	接触镀层	Tin
触头材料	Phosphor Bronze	包装数量	3500
端接排数	压接	连接器 - 电缆	contact
接触件端接	Crimp	线规或范围 - AWG	16AWG
线规或范围 - mm²	0.5...1.25mm2

产品信息

SPG	3500	连接器性别	Female
系列	SVH	适配器系列	VH
单元数量	3500	适用产品/相关产品	VH Series

环境参数

工作温度

+85°C

文档与媒体

PDF 文档

VH Connector (RoHS)
