796634-2

点击放大查看

796634-2

制造商
TE Connectivity Ltd.
描述
Conn Terminal Block F 2 POS 5.08mm Screw RA Cable Mount 15A/Contact TERM BLOCK PLUG 2POS STR 5.08MM Non-Fused Terminal Block Cable Mount 2 Way, Screw Down, 300V ac Pluggable Terminal Blocks 5.08MM RA PLUG 2P Conn Terminal Block F 2 POS 5.08mm Screw RA Cable Mount 15A/Contact Product Highlights:ConnectorHousing Color = GreenNot StackedWithout Threaded FlangeWithout Screw FlangeSearch Keywords:cage clamp, modular, one-piece, pcb, stackable, end-to-end TERMINAL BLOCK PLUGGABLE, 2POS, 30-12AWG Conn;TermBlk;Plug;2;5.08mm;SideWireEntry;30-12;Green; Pluggable terminal block; plug; female; straight; 0.03÷2.5mm2 TE Connectivity 2 路 无熔丝端子块, 电缆安装, 螺钉拧紧端接, 300 V 交流 2 POS 5.08MM R/A PLUG,TRM BLK
分类
连接器解决方案接线端子接线端子与连接器（通用型）
对参数有疑问？问 AI 助手

商业参数

产品Pluggable Terminal Blocks产品类别Pluggable Terminal Blocks
标准包装数量Bulk工厂包装数量300

合规参数

RoHSLead free / RoHS Compliant海关税号85369010
抗辐射加固No认证机构ULRecognized
材料阻燃等级UL 94 V-0

电气参数

电流15A电压300V
额定电压300 V ac极数2Poles
最大额定电流15A最小供电电压300VAC

机械参数

颜色Green深度18.4 mm
间距5.08 mm高度15.5 mm
重量0.004材料（通用）Nylon
包装方式Bulk遮蔽类型No
引脚样式Side导线线规12-30 AWG
方向straight端接方式Screw
柱间距5.08mm外壳颜色Green
安装类型Cable Mount连接器类型:Eurostyle Terminal Block
接触镀层Tin安装样式Cable
排数1插头进线方向180°
触头材料Phosphor Bronze壳体材料Polyamide (PA)
总长度10.16 mm包装数量1
主要材料PCB连接器 - 电缆plug
插针孔直径0.2(5.08)In.(mm)触点数2
位数2接线端子类型Plug, Female Sockets
进线位置Front线规或范围 - AWG30-12
线规或范围 - mm²12第一连接器安装类型:Cable
每排/每行位置数2

产品信息

SPG1类型Terminal Block
级别SingleLevel连接器性别F
系列:-产品特性Retention Latches (Non-Wire Side)
制造商全称Buchanan单元数量1
