748526-1

制造商	TE Connectivity Ltd.
描述	D-Sub Standard Connectors SHLDG HRDW KIT 9P CONN D-SUB PLUG 9POS W/O CONTACT Conn Housing PL 9 POS 2.76mm Crimp ST Bulk Conn Housing PL 9 POS 2.76mm Crimp ST Bulk Product Highlights:Connector KitProduct Series = HDP-20 (Crimp Snap)Number of Positions = 9ShieldedPlugSearch Keywords:AMPLIMITE, Office Class II Standards, Subminiature D, PC cable, MIL-C-24308, Battelle Level III, box to box, d-sub, d sub, dsub
分类	连接器解决方案D-Sub连接器

商业参数

其他名称	A23485	产品类别	D-Sub Standard Connectors
标准包装数量	100	工厂包装数量	100

合规参数

RoHS

RoHS Compliant

机械参数

颜色	Black	包装方式	Bulk
触头类型	Signal	安装类型	Free Hanging (In-Line)
连接器类型	Plug for Male Contacts	接触镀层	Tin
法兰特征	Board Side (4-40)	排数	2
连接器样式	D-Sub	触头材料	Steel
介电材料	Polyamide (PA), Nylon, Glass Filled	位数	9
外壳材料及表面处理	Steel, Tin Plated	外壳尺寸，连接器布局	1 (DE, E)

产品信息

备注	Contacts Not Provided	连接器性别	Male
系列	HDP-20	产品特性	Grounding Indents, Shielded
