1648111-1
| 制造商 | |
| 描述 | Conn Housing PL 3/16 POS Crimp ST Cable Mount High Current ELCON Drawer Connectors CONN PIN MINI DWR 16/20/16 PANEL Heavy Duty Power Connectors PIN HOUSING CONN SIZE 16 20 Conn Housing PL 3/16 POS Crimp ST Cable Mount Product Highlights:HousingContact Size = 16, 20Drawer Style = MiniPinSize 16 + Size 20 + Size 16 Contact Configuration |
| 分类 |
商业参数
| 产品类别 | Heavy Duty Power Connectors | 标准包装数量 | Bulk |
| 工厂包装数量 | 45 | ||
合规参数
| RoHS | Lead free / RoHS Compliant | ||
电气参数
| 最大额定电流 | 35 A | ||
机械参数
| 颜色 | Black | 深度 | 25.15 mm |
| 高度 | 20.07 mm | 包装方式 | Bulk |
| 外壳颜色 | Black | 安装类型 | Straight |
| 连接器类型 | Housing for Male Pins | 连接器样式 | Mini-Drawer |
| 连接器用途 | Plug | 插入力 | Male |
| 壳体材料 | Polyester | 触点数 | 3/16 |
| 位数 | 22 (16 + 6 Power) | ||
产品信息
| 备注 | Contacts Not Provided | 类型 | Housing |
| 连接器性别 | PL | 产品特性 | Mating Guide |
| 产品子类型 | Housings | ||
