1-770581-0
| 制造商 | TE Connectivity Ltd. |
| 描述 | Conn Housing PL 12 POS 4.14mm Crimp ST Panel Mount .163" Centerline, 600 V, 9.5 A max. CONN PLUG HSG 12POS MINI UMNL |
| 分类 |
商业参数
| 标准包装数量 | Bulk | ||
合规参数
| RoHS | Lead free / RoHS Compliant | 无铅定义 | Not relevant for lead free process |
| RoHS/ELV合规状态 | RoHS compliant, ELV compliant | 材料阻燃等级 | UL 94V-0 |
电气参数
| 供电电压 | 600 | 连接器类型 - 电压输入 | Mini-Universal MATE-N-LOK |
机械参数
| 颜色 | Black | 间距 | 4.14 mm |
| 锁定类型 | Positive Lock | 包装方式 | Bulk |
| 排间距 | 0.163" (4.14mm) | 触头类型 | Male or Female |
| 安装类型 | Straight | 连接器类型 | Plug |
| 紧固类型 | Latch Lock | 排数 | 2 |
| 壳体材料 | Nylon | 包装数量 | One Piece Housing |
| 触点数 | 12 | 接触件端接 | Crimp |
| 位数 | 12 | 中心触点材料 | 4.14 x 4.14 [.163 x .163] |
| 典型触点布局 | Double-Row | 接触镀层厚度 | 0.99 [0.039] |
产品信息
| 备注 | Contacts Not Provided | 类型 | Housing |
| 连接器性别 | PL | 产品子类型 | Housing |
| 模块/板类型 | No | 电路数 | 12 |
