ADS1158IRTCT

点击放大查看

ADS1158IRTCT

制造商
Texas Instruments Incorporated
描述Analog to Digital Converters - ADC 16B 16Ch 125kSPS Delta Sigma ADC Single ADC Delta-Sigma 125ksps 16-bit Serial 48-Pin VQFN EP T/R IC ADC 16BIT SER 125K 48VQFN IC, ADC 16BIT 16CH DELT-SIG 48QFN IC, ADC, 16BIT, 125KSPS, QFN-48 16 bit, 16 Channel Fast Cycling 125kSPS Delta Sigma ADC Texas Instruments , 16 位 ADC, 差分输入, SPI接口, 48针 VQFN封装
分类
集成电路数据转换器模数转换器
对参数有疑问？问 AI 助手

商业参数

其他名称296-23494-2产品类别Analog to Digital Converters - ADC
标准包装数量250工厂包装数量250
标准封装名称QFN

合规参数

RoHSRoHS CompliantSVHC:No SVHC (20-Jun-2013)
欧盟RoHSCompliant海关税号85423190
零件状态ACTIVE抗辐射加固No

电气参数

接口Serial, SPI线性度�1LSB
输入类型Single-Ended/Differential分辨率16 bit
输入信号Single-Ended|DifferentialINL/DNL（LSB）1LSB
输入功率Single/Dual额定功率62 W
转换器类型General Purpose数据接口Serial, SPI™
输入极性Unipolar|Bipolar位数16
基准类型Ext额定电压5V|±2.5V
数据速率（最大）125 KSPs额定电压值5/�2.5
输出电流:8.2mA输入数量16
供电电压+/- 2.5 V, + 5 V分辨率（位）:16bit
电压基准Internal, External通道数量16/8
元件数量1采样频率125ksps
模拟输入/输出5.25最大额定电流Catalog
ADC/DAC 数量1供电电源Single|Dual
平均正向功率42最大功耗62 mW
差分非线性±1LSB数字供电电压:2.7V to 5.25V
内部供电电压:-2.6V to 0V, 4.75V to 5.25V采样率（每秒）23.74k, 125k
差分 - 输入:输出Yes电源电压范围（典型）�2.5 V
信噪比，ADC/DAC（dB）典型值Yes

机械参数

宽度7重量0.0002
包装方式Reel引脚样式No Lead
端接方式:SMD安装类型Surface Mount
安装样式SMD/SMT引脚数:48
封装形式VQFN-48冷却的封装VQFN EP
材料表面处理:MSL 2 - 1 year总长度7
包装数量VQFN EP位数48
外壳尺寸-插件0.9供应商器件封装48-VQFN Exposed Pad (7x7)

产品信息

系列ADS1158软件SBAS429D
基本单元:1158架构Sigma-Delta
功能框图fbd_sbas429d.gif使用的IC/零件View
印刷电路板数量48A/D转换器数量1
输入数量及类型16 Single-Ended, Unipolar; 16 Single-Ended, Bipolar; 8 Differential, Unipolar; 8 Differential, Bipolar
