首页产品分类连接器解决方案D-Sub连接器D-Sub连接器749812-7
749812-7

点击放大查看

749812-7

制造商
TE Connectivity Ltd.
描述Conn D-Subminiature SKT 9 POS Crimp ST Cable Mount 9 Terminal 1 Port Bulk D-Sub Standard Connectors DSUB E09P CRIMP Standard Cable Connectors CONN D-SUB RCPT 9POS CRIMP SNAP Conn,D-Sub,CableSocket,9Pos,STR,HDP-20S Conn D-Subminiature SKT 9 POS Crimp ST Cable Mount 9 Terminal 1 Port Bulk Product Highlights:Cable Connector and ClampProduct Series = HDP-20 (Crimp Snap)Number of Positions = 9Not ShieldedReceptacleSearch Keywords:AMPLIMITE, Office Class II Standards, Subminiature D, PC cable, MIL-C-24308, Battelle Level III, box to box, d-sub, d sub, dsub D SUB CONNECTOR, STANDARD, 9POS, RCPT Conn;D-Sub;CableSocket;9Pos;STR;HDP-20Series;CrimpSnap;24-20AWG;UnshieldedKit TE Connectivity AMPLIMITE HDP-20 9触点 D-Sub 连接器套件 KIT,HDP-20,RCPT, SIZE 1, 9 POS
分类
连接器解决方案D-Sub连接器D-Sub连接器
对参数有疑问？问 AI 助手

商业参数

产品类别D-Sub Standard Connectors标准包装数量Bulk
工厂包装数量100

合规参数

RoHSRoHS Compliant标准UL94V-0
海关税号85369010无铅定义Not relevant for lead free process
认证机构ULRecognized,ULListedandCSACertifiedRoHS/ELV合规状态RoHS compliant, ELV compliant
材料阻燃等级UL 94V-0

电气参数

量程（°/s）:TE CONNECTIVITY - Amplimite HDP-20 Series额定电压250V
最大额定电流Varies by Wire Gauge

机械参数

颜色Black重量0.014
材料（通用）Stainless Steel包装方式Bulk
出线方向Straight(180°)/120°外壳尺寸1
导线线规24-20屏蔽类型No
端接方式Crimp触点尺寸20
触头类型Signal第二连接器With
外壳颜色Black安装类型Cable Mount
外壳镀层Tin over Copper行程角度Straight
电缆材料Polypropylene连接器类型Crimp Snap
接触镀层Tin over Nickel法兰特征Housing/Shell (Unthreaded)
排数2螺丝材料Steel
外壳材料（壳体）Steel绑带材料Stainless Steel
连接器样式D-Sub插入件材料Nylon
锁定特性Mounting Screws, Retainer Clip本体材料:Metal
触头材料Phosphor Bronze, Brass壳体材料Nylon, Polyester GF
包装数量Bulk主要材料D-Subminiature
电缆端接方式One-Piece Quick Snap接地凹痕Without
触点数With接触件端接:Crimp
绝缘直径1.91 – 6.35 [0.075 – 0.250]位数9
外壳尺寸-插件Full Metal Shell衬套/护套类型Without
外壳材料及表面处理Steel, Tin Plated接触镀层厚度Flash
螺钉材料 - 镀层Zinc外部壳体材料Polypropylene
线规或范围 - AWG0.2 - 0.56 [24-20]控制侧电缆固定器With
外壳尺寸，连接器布局1 (DE, E)

产品信息

类型D-Subminiature等级Standard
连接器性别SKT系列HDP-20 (Crimp Snap)
产品特性Backshell (Dual Exit), Strain Relief, Retaining Hardware制造商全称AMP
产品子类型Cable Connector and Clamp应用细节Commercial

环境参数

工作温度-55°C ~ 105°C

文档与媒体

在线文档
749812-7?RQPN=749812-7
PDF 文档
1639165.pdf
