点击放大查看
4-643813-2
| 制造商 | |
| 描述 | Conn IDC Connector F 12 POS 2.54mm IDT RA Cable Mount Loose Piece MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN RECEPT 12POS 22AWG MTA100 Conn IDC Connector F 12 POS 2.54mm IDT RA Cable Mount Loose Piece Product Highlights:Connector12 PositionsConnector Type = ReceptacleConnector Style = Closed EndMTA-100 Product LineSearch Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP WIRE-BOARD CONNECTOR RECEPTACLE 12POS, 2.54MM MTA-100CONNECTORTIN,12PMTA100CONNASSYPOLRIB 12P MTA100 CONN ASSY POL RIB |
| 分类 |
商业参数
| 标准包装数量 | Bulk | ||
合规参数
| RoHS | Lead free / RoHS Compliant | 海关税号 | 85366910 |
| 无铅定义 | Not relevant for lead free process | RoHS/ELV合规状态 | RoHS compliant, ELV compliant |
| 材料阻燃等级 | UL 94V-2 | ||
电气参数
| 额定交流电压 | 250 | ||
机械参数
| 颜色 | Red | 间距 | 2.54 mm |
| 重量 | 0.002 | 包装方式 | Bulk |
| 遮蔽类型 | No | 导线类型 | Discrete or Ribbon Cable |
| 出线方向 | 90° | 导线线规 | 22 AWG |
| 端接方式 | IDT | 触头类型 | Female Socket |
| 极化 | Polarizing Tab | 第二连接器 | With |
| 基体材料 | :Nylon | 外壳颜色 | Red |
| 安装类型 | Free Hanging (In-Line) | 连接器类型 | Closed End |
| 接触镀层 | Tin Over Nickel | 紧固类型 | Locking Ramp |
| 排数 | 1 | 连接器用途 | Receptacle |
| 触头材料 | Copper Alloy | 壳体材料 | Nylon |
| 安装特性 | Without | 包装数量 | Loose Piece |
| 面板安装类型 | Without | 主要材料 | InterconnectSystem |
| 电缆端接方式 | IDC | 配接方向 | With |
| 触点数 | 12 | 接触件端接 | :IDC / IDT |
| 位数 | 12 | 典型触点布局 | 2.54 [0.100] |
| 接触镀层厚度 | 80µin (2.03µm) | 恢复后小径 | No |
| 线规或范围 - mm² | 0.3-0.4² [22] | ||
产品信息
| 类型 | IDC Connector | 连接器性别 | F |
| 产品特性 | Closed End | 制造商全称 | AMP |
| 产品子类型 | MTA-100 Connectors | 连接类型 | Wire |
| 跳过的位置数 | None | ||
相关型号
1-640456-2
te connectivity / amp
Conn Wire to Board HDR 12 POS 2.54mm Solder ST Thru-Hole MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN HEADER VERT 12POS .100 TIN TE Connectivity MTA-100 Series 2.54mm Pitch 12 Way 1 Row Straight PCB Header, Solder Termination, 5A Headers & Wire Housings FRICTION LCK HDR 12P Straight Post tin Conn Wire to Board HDR 12 POS 2.54mm Solder ST Thru-Hole Product Highlights:MTA-100 ConnectorsNumber of Positions = 12Mating Type = HeaderWire-to-Board Application2.54 mm Contact Centerline SpacingSearch Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP HEADER, VERTICAL, 0.1", 12WAY Header,FrictionLock;MTA-100;12;250VAC;Polyester;Tin;CopperAlloy;Tin Pin header 12P, 1-640456-2, TE Connectivity TE Connectivity MTA-100 系列 2.54mm节距 12路 (1排) 直 PCB 针座, 焊接端接, 5A , 通孔 12P MTA100 HDR ASSY F/L SQ STR
1-641216-2
te connectivity / amp
Conn Wire to Board HDR 12 POS 2.54mm Solder RA Thru-Hole CONN HEADER RT/A 12POS .100 30AU Conn Wire to Board HDR 12 POS 2.54mm Solder RA Thru-Hole Product Highlights:MTA-100 ConnectorsNumber of Positions = 12Mating Type = HeaderWire-to-Board Application2.54 mm Contact Centerline Spacing
4-644456-2
te connectivity / amp
Conn Unshrouded Header HDR 12 POS 2.54mm Solder ST Thru-Hole MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN HEADER VERT 12POS .100 TIN Headers & Wire Housings NARROW FLT HDR 12P Straight Post Conn Unshrouded Header HDR 12 POS 2.54mm Solder ST Thru-Hole Search Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP WIRE-BOARD CONN, HEADER, 12WAY, 0.1IN 12P MTA100 HDR ASSY (NARROW)
1-647166-2
te connectivity / amp
Conn Wire to Board HDR 12 POS 2.54mm Solder ST SMD MTA-100 CL Connectors CONN HEADER 12POS .100 STR TIN Headers & Wire Housings 12P MTA100 HDR ASSY SM,FL,SN MTA, CST-100 II, MT-6 and SL Connectors and Headers MTA, CST-100 II, MT-6 and SL Connectors and Headers Product Highlights:12 PositionsPreloadedHousing Gender = Header - PinContact Gender = PinMTA-100 Product LineSearch Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP 12P MTA100 HDR ASSY,SM,FL,SN
4-644457-2
te connectivity / amp
Conn Unshrouded Header HDR 12 POS 2.54mm Solder RA Thru-Hole MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN HEADER RT/A 12POS .100 TIN Headers & Wire Housings 12P HDR ASSY R/A NARROW Conn Unshrouded Header HDR 12 POS 2.54mm Solder RA Thru-Hole Product Highlights:Connector12 PositionsConnector Type = Header - PinMTA-100 Product LineWire-to-Board ApplicationSearch Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP 12P MTA100 HDR ASSY R/A NARROW
1-647116-2
te connectivity / amp
Conn Wire to Board HDR 12 POS 2.54mm Solder ST Thru-Hole MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN HEADER 12POS VERT .100 GOLD Headers & Wire Housings 12P MTA100 HDR HT FL STR 30AU 12P MTA100 HDR HT FL STR 30AU 12P MTA100 HDR HT FL STR 30AU Search Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP
4-644695-2
te connectivity / amp
Conn Unshrouded Header HDR 12 POS 2.54mm Solder ST Thru-Hole MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN HEADER VERT 12POS .100 TIN Headers & Wire Housings NARROW FLT HDR 12P Strt Post w/ret. leg 12P MTA100 STR HDR RETENTIVE 12P MTA100 STR HDR RETENTIVE Search Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP
3-644486-2
te connectivity / amp
Conn Shrouded Header HDR 12 POS 2.54mm Solder ST Thru-Hole MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN HEADER VERT 12POS .100 TIN Headers & Wire Housings HDR 12P VRT SHROUD Conn Shrouded Header HDR 12 POS 2.54mm Solder ST Thru-Hole Search Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP 12P MTA100 SHRDED HDR ASSY SN
1-647016-2
te connectivity / amp
Conn IDC Connector F 12 POS 2.54mm IDT ST Cable Mount MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN RCPT 12POS .100 GOLD Headers & Wire Housings 12P MTA100 PSTD CONN ASSY 15AU MTA, CST-100 II, MT-6 and SL Connectors and Headers Product Highlights:MTA-100 ConnectorsNumber of Positions = 12Mating Type = ReceptacleConnector Type = Closed EndWire-to-Wire ApplicationSearch Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP 12P MTA100 PSTD CONN ASSY 15AU
4-647002-2
