首页产品分类连接器解决方案板对板连接器板对板连接器1-640456-2
1-640456-2

点击放大查看

1-640456-2

制造商
TE Connectivity Ltd.
描述
Conn Wire to Board HDR 12 POS 2.54mm Solder ST Thru-Hole MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN HEADER VERT 12POS .100 TIN TE Connectivity MTA-100 Series 2.54mm Pitch 12 Way 1 Row Straight PCB Header, Solder Termination, 5A Headers & Wire Housings FRICTION LCK HDR 12P Straight Post tin Conn Wire to Board HDR 12 POS 2.54mm Solder ST Thru-Hole Product Highlights:MTA-100 ConnectorsNumber of Positions = 12Mating Type = HeaderWire-to-Board Application2.54 mm Contact Centerline SpacingSearch Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP HEADER, VERTICAL, 0.1", 12WAY Header,FrictionLock;MTA-100;12;250VAC;Polyester;Tin;CopperAlloy;Tin Pin header 12P, 1-640456-2, TE Connectivity TE Connectivity MTA-100 系列 2.54mm节距 12路 (1排) 直 PCB 针座, 焊接端接, 5A , 通孔 12P MTA100 HDR ASSY F/L SQ STR
分类
连接器解决方案板对板连接器板对板连接器
对参数有疑问？问 AI 助手

商业参数

产品类别Headers & Wire Housings标准包装数量Bulk
工厂包装数量1000

合规参数

RoHSLead free / RoHS Compliant欧盟RoHSCompliant
标准RoHSCompliant,ELVCompliant,UL94V-0海关税号85369010
无铅定义Wave solder capable to 240°C, Wave solder capable to 260°C, Wave solder c认证机构CSA,UL
RoHS/ELV合规状态RoHS compliant, ELV compliant材料阻燃等级UL 94V-0

电气参数

量程（°/s）:TE - MTA-100 Series额定电压250 V ac
开关功能Friction Lock接触电阻6 mohm
额定交流电压250最大额定电流5A
最小输入电压250VAC最小供电电压250VAC

机械参数

颜色Natural深度5.72 mm
间距2.54 mm高度10.03 mm
重量0.01包装方式Bulk
端口尺寸0.025in.遮蔽类型No
端接方式Solder触头类型Male Pin
引脚间距:2.54mm引脚长度（针脚）0.14"
极化Polarizing Slot第二连接器With
触点形状Square外壳颜色White
安装类型Through Hole行程角度Straight
连接器类型Header, Unshrouded接触镀层Tin
紧固类型Friction Lock安装样式Through Hole
排数1连接器用途Header
锁定特性Friction Lock触头材料Copper Alloy
壳体材料Polyester总长度30.48 mm
安装特性Without包装数量500
面板安装类型Without主要材料InterconnectSystem
尺寸/外形0.64 [.025]插针孔直径0.1"
端接样式Through Hole第一触头极性Pin (Male)
连接器颜色:White配接方向With
触点数12接触件端接:Through Hole Vertical
位数12后壳中断功能Without
中心触点镀层工艺0.100in.柱体长度（配合）0.14in.
安装孔直径0.04"接触长度 - 配合0.295" (7.49mm)
触点材料 - 柱Copper Alloy端子柱长度3.56 [0.140]
恢复后小径No

产品信息

类型Wire to Board连接器性别HDR
系列MTA-100CAD图纸3D CAD Model
制造商全称AMP产品子类型MTA-100 Connectors
连接类型Printed Circuit Board应用细节Wire-to-Board
加载位置数All跳过的位置数None

环境参数

工作温度-55C to 105C

文档与媒体

在线文档
1-640456-2
