点击放大查看
1658677-1
| 制造商 | TE Connectivity Ltd. |
| 描述 | Conn D-Subminiature PIN 44 POS Crimp ST Cable Mount 44Terminal 1Port Bulk D-Sub High Density Connectors DSUB B44P CRIMP KIT Standard Cable Connectors CONN D-SUB PLUG 44POS W/O CONT D-Sub Standard Connectors DSUB B44P CRIMP KIT Conn Housing PL 44 POS 2.28mm Crimp ST Cable Mount Bulk Conn Housing PL 44 POS 2.28mm Crimp ST Cable Mount Bulk Product Highlights:Connector KitProduct Series = HDP-22 (Crimp Snap)Number of Positions = 44ShieldedPlugSearch Keywords:AMPLIMITE, Office Class II Standards, Subminiature D, PC cable, MIL-C-24308, Battelle Level III, box to box, d-sub, d sub, dsub Conn;D-Sub;CablePlug;44Pos;STR;HDP-22Series;CrimpSnap;22AWG;ShieldingHDWRKit HDP22 Series 44 Position Shielding Hardware Plug Metal Kit D-Sub HDP-22,OVRMLD,PLUG KIT,SIZE 3, |
| 分类 |
商业参数
| 其他名称 | A31503 | 产品类别 | D-Sub High Density Connectors |
| 标准包装数量 | Tape & Reel | 工厂包装数量 | 100 |
合规参数
| RoHS | RoHS Compliant | 标准 | Insert,UL94V-0 |
| 防护类型 | UL 94V-0 | 材料阻燃等级 | UL 94V-0 |
电气参数
| 最小供电电压 | 250VAC | ||
机械参数
| 颜色 | Black | 高度 | 12.92 mm |
| 外形尺寸(长x宽) | 3 | 锁定类型 | 不带 |
| 包装方式 | Bulk | 屏蔽 | 是 |
| 外壳尺寸 | 3 | 导线线规 | 22 |
| 端接方式 | Crimp | 触头类型 | Signal |
| 外壳表面处理 | 锡 | 外壳颜色 | Black |
| 安装类型 | Cable Mount | 外壳镀层 | Tin |
| 端子尺寸 | 22 | 线径 | 4.19 – 11.56 mm [ .165 – .455 in ] |
| 行程角度 | Straight | 连接器类型 | Plug for Male Contacts |
| 法兰特征 | Housing/Shell (Unthreaded) | 排数 | 2 |
| 外壳材料（壳体） | Steel | 连接器样式 | D-Sub, High Density |
| 插入件材料 | Thermoplastic | 屏蔽材料 | Steel |
| 壳体材料 | Nylon | 总长度 | 53.41 mm |
| 包装数量 | 1 | 主要材料 | D-Subminiature |
| 端接样式 | Crimp | 触点数 | 44 POS |
| 介电材料 | Polyamide (PA), Nylon, Glass Filled | 位数 | 44 |
| 外壳镀层厚度 | 200µin (5.08µm) | 外壳材料及表面处理 | Steel, Tin Plated |
| 外壳尺寸，连接器布局 | 3 (DB, B) High Density | ||
产品信息
| 备注 | Contacts Not Provided | 类型 | D-Subminiature |
| 等级 | 标准 | 连接器性别 | PIN |
| 产品特性 | Grounding Indents, Shielded | 制造商全称 | HDP-22 |
| 产品子类型 | 连接器 | ||
环境参数
| 工作温度 | -55C to 105C | ||
