点击放大查看
HC4-HSF-K
| 制造商 | Panasonic Corporation |
| 描述 | Relay Sockets & Hardware FOR HC4 RELAYS FRONT WIRE Conn Relay Socket SKT 14 POS Screw ST Thru-Hole SOCKET SCRW FRONT WIRE HC4 RELAY Socket; Screw Terminal; PCB Mount; 67 mm; 27.8 mm; 30 mm RELAY SOCKET Socket,Relay;ScrewTerminal;PCBMount;67mm;27.8mm;30mm HC4 Relay Socket (4 POLE NON DIN RAIL) HC Series Socket Screw front wire for HC4 Relays 继电器插座, 适用于HC 系列继电器 |
| 分类 |
商业参数
| 产品类别 | Relay Sockets & Hardware | 标准包装数量 | 20 |
| 工厂包装数量 | 20 | ||
合规参数
| RoHS | RoHS Compliant By Exemption | 欧盟RoHS | Compliant |
| 海关税号 | 85366910 | ||
电气参数
| 额定电压 | :250VAC | 接触电阻 | 30 |
| 最大额定电流 | :10A | 最小输入电压 | 250VAC |
机械参数
| 深度 | 30 | 宽度 | 30mm |
| 高度 | 27.8mm | 长度 | 67mm |
| 重量 | 0.045 | 包装方式 | Bulk |
| 端接方式 | Screw | 插座深度（或方向） | ScrewTerminal |
| 安装类型 | Through Hole | 连接器类型 | :Screw |
| 安装样式 | PCBMount | 引脚数 | :14 |
| 排数 | 4 | 触头材料 | Gold/Silver Alloy |
| 总长度 | 67 | 端接样式 | Screw |
| 触点数 | 14 | 位数 | 14 |
产品信息
| 类型 | Relay Socket | 连接器性别 | SKT |
| 系列 | HC1-H, HC2-H, HC4-H | 产品特性 | Mounting Hardware |
| 附件类型 | Sockets | 有铅工艺兼容 | :Yes |
| 适用产品/相关产品 | HC4 Relays | ||
文档与媒体
相关型号
HC2K-DC100V-F
