HC4-HL-AC100V
| 制造商 | Panasonic Corporation |
| 描述 | General Purpose Relays RELAY PWR 4PDT 5A 100VAC PLUG IN RELAY GEN PURPOSE 4PDT 5A 100V Electromechanical Relay 4PDT 5A 100/110VAC Plug-In |
| 分类 |
商业参数
| 标准包装数量 | 20 | ||
合规参数
| RoHS | RoHS Compliant | ||
电气参数
| 线圈类型 | Single Side Stable | 线圈功率 | 1.2 VA |
| 线圈电流 | 13.2mA | 释放时间 | 20ms |
| 供电电压 | 100 V, 110 V | 开关电压 | 250VAC - Max |
| Vgs(th)（最大）@ Id | 30 VAC | 平均正向功率 | 1.3 VA at 50 Hz, 1.2 VA at 60 Hz |
| 集电极-发射极饱和电压（最大）@ Vge, Ic | 80 VAC | 触点额定电流 | 5A |
机械参数
| 包装方式 | Bulk | 触点形式 | 4 Form C (4PDT-BM) |
| 安装类型 | Socketable | 安装样式 | Plug In |
| 触头材料 | Silver Nickel | 端接样式 | Quick Connect |
| 接触件端接 | Quick Connect | ||
产品信息
| 产品特性 | LED Indicator | 继电器类型 | General Purpose |
环境参数
| 动作时间 | 20ms | 工作温度 | -50°C ~ 60°C |
