首页产品分类连接器解决方案FFC/FPC连接器FFC/FPC连接器15-38-8030

点击放大查看

15-38-8030

制造商	Molex, LLC
描述	CONN FFC FEMALE 3POS .100 TIN FFC & FPC Connectors SL FFC/FPC Opt G Fem 3CKT TIN Conn IDC Connector F 3 POS 2.54mm IDT ST Cable Mount Tube
分类	连接器解决方案FFC/FPC连接器FFC/FPC连接器

对参数有疑问？问 AI 助手

商业参数

商标名	C-Grid	零件号别名	0015388030 70430-0142
产品类别	FFC & FPC Connectors	标准包装数量	1
工厂包装数量	2100

合规参数

RoHS

RoHS Compliant

材料阻燃等级

UL94 V-0

电气参数

额定电压

250V

最大额定电流

1 A, 2 A

机械参数

颜色	Black	间距	0.100" (2.54mm)
包装方式	Tube	端接方式	IDC
安装类型	Vertical	连接器类型	Receptacle
接触镀层	Tin	安装样式	Cable
触头材料	Phosphor Bronze	壳体材料	Polyester, Glass Filled
端接样式	IDC	FFC/FCB厚度	0.30mm
触点数	3	位数	3
接触镀层厚度	150µin (3.81µm)

产品信息

连接器性别	Female	系列	70430
产品特性	Latch Lock	产品子类型	Free Hanging

环境参数

工作温度

-40°C ~ 105°C
