GPIODM-KPLCD
| 制造商 | Microchip Technology Inc. |
| 描述 | GPIO Expander Keypad And LCD Demo Board Development Boards & Kits - PIC / DSPIC GPIO EXPNDER DEMO BD BOARD DEMO LCD GPIO EXP KEYPAD GPIODM-KPLCD, Development Kit, Serial MCP23017, GPIO EXPANDER, DEMO BOARD DEMOBOARD,GPIODM-KPLCD Microchip GPIO Expander Keypad & LCD HMI接口 演示板 |
| 分类 |
商业参数
| 产品 | Demonstration Boards | 其他名称 | GPIODMKPLCD |
| 产品类别 | Development Boards & Kits - PIC / DSPIC | 标准包装数量 | Boxed |
| 工厂包装数量 | 1 | ||
合规参数
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| 欧盟RoHS | Supplier Unconfirmed | 海关税号 | 85423190 |
电气参数
| 核心类型 | PIC | 接口 | I2C, SPI |
| 供电电压 | 5 V | 元件数量 | :PIC18F |
机械参数
| 重量 | 0.4 | 核心数/总线宽度 | 8 bit |
产品信息
| 类型 | Development Kit | 内容 | Board, Software |
| 嵌入式 | Yes, MCU, 8-Bit | 产品特性 | :SPI and I2C Buses, Keypad and LCD Interface, ICSP Header |
| 功能 | GPIO expnader keypad and LCD demonstration board | 技术 | GPIO Expanders |
| 套件内容 | :Board | 主要用途 | Interface, Front Panel Controller, LCD |
| 制造商全称 | :PIC18F4xxx | 卡标准 | Development Kit |
| 工具类型/特性 | :Demo Board | 主要特性 | (2) 8-Bit and (2) 16-Bit GPIO Expanders, 4x4 Keypad, 2x16 LCD |
| 使用的IC/零件 | MCP23008, MCP23S08, MCP23017, MCP23S17, PIC18F4550, MCP1702 | 芯片组制造商 | :Microchip |
| 次要特性 | Headers for the MCP23x08 and MCP23x17 | 支持MCU系列 | :PICmicro |
| 适用产品/相关产品 | :MCP23S08/17, MCP23008/17 | ||
