点击放大查看
01550400Z
| 制造商 | |
| 描述 | Fuse Holders Inline Fuse Holder 20A 32V Wire In Line ACS In-Line Fuseholder for ATO FUSE HLDR BLADE 32V 30A PNL MNT FUSE HOLDER, IN LINE Fuse Holder Inline |
| 分类 |
商业参数
| 最小起订量 | 1 | 产品 | Fuse Holders |
| 单位包装 | 1 | 产品类别 | Fuse Holders |
| 标准包装数量 | 1 | 工厂包装数量 | 1 |
合规参数
| RoHS | RoHS Compliant | 海关税号 | 85361010 |
| 汽车级 | NO | 无铅定义 | RoHS-conform |
电气参数
| 电压 | 32V | 额定电压 | 32 V |
| 极数 | 1 | 额定交流电压 | :32V |
| 最大额定电流 | 30 A | 触点电压（最大） | :32V |
| 每极负载侧连接方式 | :Wire Leaded | ||
机械参数
| 颜色 | Black | 深度 | Not Required mm |
| 高度 | Not Required mm | 长度 | 55.63 |
| 重量 | 0.018 | 包装方式 | Bulk |
| 安装类型 | Panel Mount | 接触镀层 | Tin |
| 安装样式 | In-Line | 保险丝座类型 | Holder |
| 触头材料 | Brass | 总长度 | 55.63 mm |
| 端接样式 | Wire Leads | 外径 | 15.24 |
产品信息
| 类型 | Fuse Holder | 系列 | 01550400 |
| 保险丝尺寸 | 0.75" L x 0.2" W x 0.74" H (19.1mm x 5.1mm x 18.8mm) | 保险丝类型 | Blade |
| 匹配码 | FUHAUTO 30A | 照明类型 | No |
| 标准交期 | 14 weeks | 电路数 | 1 |
| 附带电池数量 | :1 | 适用产品/相关产品 | ATC, ATO |
环境参数
| 工作温度 | - 40 C to + 85 C | 结工作温度 | -40C |
