点击放大查看
2058703-3
| 制造商 | |
| 描述 | Conn Board to Board M 6 POS 4mm Solder RA SMD T/R Lighting Connectors BLADE AND RCPT 6 POS SMT WHT CONN RCPT&BLADE 6POS W/LATCH SMD TE Connectivity 2058703 Series 4mm Pitch 6 Way 1 Row Right Angle Lighting Connectors, Solder Termination, 6A Conn Board to Board M 6 POS 4mm Solder RA SMD T/R Product Highlights:ConnectorPreloadedHousing Gender = HermaphroditicProduct Classification = Board-to-Board6 Positions CONNECTOR, BLADE & RECEPTACLE, 6WAY CON,BLADE+RECP,SMT,6W,WHT CONN RCPT&BLADE 6POS Hermaphroditic connector with latch 6P, 2058703-3, TE Connectivity TE Connectivity Hermaphroditic 系列 4mm节距 6路 (1排) 直角 照明连接器, 焊接端接, 6A , 表面安装 Herm Blade& Recp Assy,6 Pos,Latch |
| 分类 |
商业参数
| 产品 | Connectors | 其他名称 | A99883DKR |
| 产品类别 | Lighting Connectors | 标准包装数量 | Tape & Reel |
合规参数
| RoHS | Lead free / RoHS Compliant | 海关税号 | 85369010 |
| 材料阻燃等级 | UL 94 V-0 | ||
电气参数
| 额定电压 | 125 V ac/dc | 击穿电压 | :1500V |
| 最大额定电流 | 6A | ||
机械参数
| 颜色 | White | 间距 | 4 mm |
| 重量 | 0.01 | 包装方式 | Tape & Reel (TR) |
| 端接方式 | Solder | 触头类型 | Blade/Socket |
| 外壳颜色 | Natural | 安装类型 | Surface Mount, Right Angle |
| 接触镀层 | Tin Over Nickel | 排数 | 1 |
| 触头材料 | Copper Alloy | 壳体材料 | Liquid Crystal Polymer (LCP) |
| 端接样式 | SMD | 连接器颜色 | :White |
| 触点数 | 6 | 接触件端接 | :Solder |
| 位数 | 6 | ||
产品信息
| 类型 | Board to Board | 样式 | Board to Board or Cable |
| 连接器性别 | M | 系列 | 2058703 |
| 产品特性 | Latch Lock | 应用细节 | Board to Board |
环境参数
| 工作温度 | :105°C | ||
