首页产品分类连接器解决方案板对板连接器板对板连接器2-644486-4
2-644486-4

点击放大查看

2-644486-4

制造商
TE Connectivity Ltd.
描述Conn Shrouded Header HDR 4 POS 2.54mm Solder ST Thru-Hole MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN HEADER VERT 4POS .100 TIN Headers & Wire Housings SHROUDED HEADER 4P Straight Post tin Conn Shrouded Header HDR 4 POS 2.54mm Solder ST Thru-Hole Product Highlights:MTA-100 ConnectorsNumber of Positions = 4Mating Type = HeaderWire-to-Board Application2.54 mm Contact Centerline SpacingSearch Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP MTA-100SHROUDEDHDR,04PMTA100SHRDEDHDRASSYSN TE Connectivity MTA-100 系列 2.54mm节距 4路 (1排) 直 PCB 针座, 焊接端接, 5A , 通孔 04P MTA100 SHRDED HDR ASSY SN
分类
连接器解决方案板对板连接器板对板连接器

商业参数

产品类别Headers & Wire Housings标准包装数量Bulk
工厂包装数量1

合规参数

RoHSLead free / RoHS CompliantUL等级获得认可
无铅定义Wave solder capable to 240°CUL档案号E28476
CSA档案号LR7189标准编号CSA, UL
CSA认证CertifiedRoHS/ELV合规状态RoHS compliant, ELV compliant
材料阻燃等级UL 94V-0

电气参数

额定电压250 V开关功能Friction Lock
供电电压250接触电阻10 mohm
额定交流电压250连接器阻抗焊接
最大额定电流5 A最小供电电压250VAC

机械参数

颜色Black深度7.95 mm
间距2.54 mm高度10.42 mm
长度12.29 mm [ .484 in ]包装方式Bulk
遮蔽类型Yes壳体颜色黑色
方向直端接方式Solder
触头类型Male Pin极化Polarized Retention Peg
第二连接器Without触点形状Square
外壳颜色White安装类型Vertical
连接器类型Header, Shrouded接触镀层Matte Tin
触点时序Without紧固类型Friction Lock
安装样式Through Hole排数1
壳体镀层Tin外壳材料（壳体）摩擦锁
连接器用途Header插入件材料铜合金
触头材料Copper Alloy壳体材料Polyester
总长度12.29 mm安装特性Without
包装数量500面板安装类型Without
尺寸/外形0.64 [.025]端接排数焊接
端接样式Through Hole第一触头极性Pin (Male)
配接方向Without触点数4
端接表面处理不带位数4
后壳中断功能Without兼容外壳尺寸（如TM-700等）MTA .100 连接器组件
触头长度-柱3.56 mm [ .14 in ]安装孔直径带有
接触件表面处理 - 配合锡典型触点布局同轴
接触长度 - 配合0.200" (5.08mm)触点材料 - 柱Copper Alloy
端子柱长度5.1 mm [ .2 in ]接触镀层厚度3.81 – 6.3 µm [ 150 – 250 µin ]
恢复后小径No静电放电屏蔽不带
护套（绝缘）厚度1.27 µm, 50 µin

产品信息

类型Shrouded Header连接器性别HDR
系列MTA-100覆盖范围覆盖
产品特性Board Guide可密封否
制造商全称AMP产品子类型MTA-100 Connectors
连接类型Printed Circuit Board应用细节Wire-to-Board
加载位置数All跳过的位置数None

环境参数

工作温度-55C to 105C封装热阻1.6 mm [ .063 in ]

文档与媒体

2-644486-4

相关型号

644540-4

644540-4

te connectivity / amp

Conn IDC Connector F 4 POS 2.54mm IDT RA Cable Mount Loose Piece MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN RECEPT 4POS 22AWG MTA100 Headers & Wire Housings FEED THRU W/TAB 4P red tin 22 AWG Conn IDC Connector F 4 POS 2.54mm IDT RA Cable Mount Loose Piece Product Highlights:MTA-100 ConnectorsNumber of Positions = 4Mating Type = ReceptacleConnector Type = Feed ThruWire-to-Board ApplicationSearch Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP 04P MTA100 CONN ASSY F/T W/LCK
