首页产品分类连接器解决方案压接与焊接端子/接头压接端子（通用）1-87175-8

点击放大查看

1-87175-8

制造商	TE Connectivity Ltd.
描述	Conn Housing RCP 8 POS 2.54mm Crimp ST Cable Mount Headers & Wire Housings CONN HOUSING 8 POS SINGLE ROW .100 AMPMODU Headers, Housings & Contacts CONN HOUSING 8POS .100 LOCKING .100 AMP housing locking clip,8way Conn Housing RCP 8 POS 2.54mm Crimp ST Cable Mount Product Highlights:HousingNot PreloadedNumber of Positions = 8Housing Type = ReceptacleNumber of Rows = SingleSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE WIRE-BOARD CONNECTOR RECEPTACLE, 8POS, 2.54MM .100AMPhousinglockingclip,8way TE Connectivity AMPMODU 系列 2.54mm 节距 8 路直母电缆安装 PCB 壳体 08 LOCKING CLIP HSG SR .100CL
分类	连接器解决方案压接与焊接端子/接头压接端子（通用）

商业参数

商标名	AMPMODU	其他名称	A26929
产品类别	Headers & Wire Housings	标准包装数量	Bulk
工厂包装数量	1

合规参数

RoHS

RoHS Compliant

海关税号

85366930

电气参数

量程（°/s）	:TE - AMPMODU Series	额定电压	250 VAC
最大额定电流	3 A	最小供电电压	250VAC

机械参数

颜色	Black	深度	17.78mm
间距	2.54 mm	宽度	4.44mm
高度	4.44 mm	长度	20.72mm
重量	0	包装方式	Bulk
导线线规	22-30 AWG	排间距	2.54 mm
触头类型	Female Socket	外壳颜色	Black
安装类型	Straight	连接器类型	Receptacle
接触镀层	:-	安装样式	SMD/SMT
排数	1	触头材料	:-
壳体材料	Polyester	总长度	20.72 mm
主要材料	Connector	端接样式	Crimp
第一触头极性	Socket (Female)	配接方向	QuickDisconnect
触点数	8	接触件端接	Crimp
位数	8

产品信息

备注	Contacts Not Provided	类型	Housing
连接器性别	RCP	系列	AMPMODU Locking Clip
制造商全称	AMPMODU	产品子类型	Receptacles / Sockets - Housings
应用细节	Board-to-Board	适用产品/相关产品	Centerline Single-Row Connector

环境参数

工作温度

- 65 C to + 105 C

文档与媒体

1-87175-8

1-87175-8?RQPN=1-87175-8
