1-640456-6

点击放大查看

1-640456-6

制造商
TE Connectivity Ltd.
描述
Conn Wire to Board HDR 16 POS 2.54mm Solder ST Thru-Hole MTA, CST-100 II, MT-6 and SL Connectors and Headers CONN HEADER VERT 16POS .100 TIN TE Connectivity MTA-100 Series 2.54mm Pitch 16 Way 1 Row Straight PCB Header, Solder Termination, 5A Headers & Wire Housings FRICTION LCK HDR 16P Straight Post tin Conn Wire to Board HDR 16 POS 2.54mm Solder ST Thru-Hole Product Highlights:MTA-100 ConnectorsNumber of Positions = 16Mating Type = HeaderWire-to-Board Application2.54 mm Contact Centerline SpacingSearch Keywords:5 A, 250 VAC, 7 A, 600 VAC, PCB Connectors, Ribbon Cable, Ribbon and Flat Flex Wire, LID, Large Insulation Diameter, IDC Quad Connectors, Discrete Wire Connectors, PWRSIGALLP CONNECTOR, HEADER, 2.54MM, 16WAY Header,FrictionLock;MTA-100;16;250VAC;Polyester;Tin;CopperAlloy;Tin TE Connectivity MTA-100 系列 2.54mm节距 16路 (1排) 直 PCB 针座, 焊接端接, 5A , 通孔 16P MTA100 HDR ASSY F/L SQ STR
分类
连接器解决方案板对板连接器板对板连接器
对参数有疑问？问 AI 助手

商业参数

产品类别Headers & Wire Housings标准包装数量Bulk
工厂包装数量10

合规参数

RoHSLead free / RoHS Compliant欧盟RoHSCompliant
标准RoHSCompliant,ELVCompliant,UL94V-0海关税号85366930
无铅定义Wave solder capable to 240°C, Wave solder capable to 260°C, Wave solder c认证机构CSA,UL
RoHS/ELV合规状态RoHS compliant, ELV compliant材料阻燃等级UL 94V-0

电气参数

量程（°/s）:TE - MTA-100 Series额定电压250 V ac
开关功能Friction Lock接触电阻6 mohm
额定交流电压250最大额定电流5A
最小输入电压250VAC最小供电电压250VAC

机械参数

颜色Natural深度5.72 mm
间距2.54 mm高度10.03 mm
重量0.00181包装方式Bulk
端口尺寸0.025in.遮蔽类型No
端接方式Solder触头类型Male Pin
引脚长度（针脚）0.14"极化Polarizing Slot
第二连接器With触点形状Square
外壳颜色White安装类型Through Hole
行程角度Straight连接器类型Header, Unshrouded
接触镀层Tin紧固类型Friction Lock
安装样式Through Hole排数1
连接器用途Header锁定特性Friction Lock
触头材料Copper Alloy壳体材料Polyester
总长度40.64 mm安装特性Without
面板安装类型Without主要材料InterconnectSystem
尺寸/外形0.64 [.025]插针孔直径0.1"
端接样式Through Hole第一触头极性Pin (Male)
配接方向With触点数16
接触件端接:Through Hole Vertical位数16
后壳中断功能Without中心触点镀层工艺0.100in.
柱体长度（配合）0.14in.安装孔直径0.04"
接触长度 - 配合0.295" (7.49mm)触点材料 - 柱Copper Alloy
端子柱长度3.56 [0.140]恢复后小径No

产品信息

类型Wire to Board连接器性别HDR
系列MTA-100CAD图纸3D CAD Model
制造商全称AMP产品子类型MTA-100 Connectors
连接类型Printed Circuit Board应用细节Wire-to-Board
加载位置数All跳过的位置数None

环境参数

工作温度-55C to 105C

文档与媒体

在线文档
1-640456-6

相关型号

1-643814-6

1-643814-6

te connectivity / amp
