1765784

点击放大查看

1765784

制造商
Phoenix Contact GmbH & Co. KG
描述Pluggable Terminal Blocks MSTBP 2.5/ 3-ST Conn Terminal Block F 3 POS 5mm Screw RA Cable Mount 12A TERM BLOCK PLUG 3POS STR 5MM MSTBP25/3-ST Phoenix Contact COMBICON MSTBP 系列 5mm 节距 3 路 母 绿色 插头, 螺钉端接
分类
连接器解决方案接线端子螺丝接线端子
对参数有疑问？问 AI 助手

商业参数

产品Plugs商标名COMBICON Control
产品类别Pluggable Terminal Blocks标准包装数量50
工厂包装数量50

合规参数

RoHSLead free / RoHS Compliant欧盟RoHSCompliant

电气参数

电流15A电压300V
额定电压250 V最大额定电流12 A
最小输入电压320V

机械参数

颜色Green深度15mm
间距0.197" (5.00mm)高度15
重量7 lbs材料（通用）聚酰胺，镀锡
包装方式Bulk导线线规12-30 AWG
端接方式Screw安装类型Cable Mount
连接器类型母座接触镀层Tin
排数1插头进线方向180°
壳体材料Polyamide总长度15
端接排数螺钉端接样式Screw
触点数3位数3
接线端子类型Plug, Female Sockets线规或范围 - AWG24-12

产品信息

类型Terminal Block连接器性别F
系列MSTBP产品特性Retention Latches (Non-Wire Side)
层数1每层位数3
