H3YN-41 AC24

制造商	Omron Corporation
描述	Timers Timer Mini-Multi Timer Electromechanical Relay 4PDT 3A 24VAC Plug-In TIMER MINI MULTI-TIME 4PDT 24V Time Delay Relay Omron H3YN-41 AC24, 0.1 min to 10 h Socket 4PDT 250V ac 欧姆龙(OMRON) 时间继电器 Omron 多功能延时继电器, 0.1 min → 10 h, 4触点, 4PDT, 24 V 交流
分类	工业电源组件和继电器时间延迟继电器数字定时器

对参数有疑问？问 AI 助手

商业参数

产品类别	Timers	标准包装数量	1
工厂包装数量	1

合规参数

RoHS

RoHS Compliant

欧盟RoHS

Compliant

电气参数

电路	4PDT (4 Form C)	延迟时间	0.1 Min ~ 10 Hrs
输出类型	Mechanical Relay	量程（°/s）	0.1 分钟→ 10 h
最大电压	250 V ac	工作模式	Flicker OFF Start, Flicker ON Start, Interval, ON Delay
可见输出	No	推频（MHz/V）	No
关断延迟时间	小时，分钟	供电电压	24VAC
供电类型	External	钳位电压	20.4VAC
二极管配置	Yes	最大额定电流	3 A
最小输入电压	2.4VAC	开关功能/额定值	4PDT
启动定时方式	Input Voltage	触点额定值 @ 电压	3A @ 250VAC

机械参数

密封	Unsealed	深度	63mm
宽度	21.5mm	高度	56.6
长度	28mm	触点形式	4 Form C
安装类型	Plug-In	端子类型	Socket
连接器类型	插座	总长度	28
端接样式	Solder Lug	触点数	14
典型触点布局	4PDT

产品信息

类型	Time Delay Relay	系列	H3YN
功能	Programmable (Multi-Function)	继电器类型	Time Delay
CAD图纸	3D CAD 模型	开关类型	4PDT
定时器数量	多功能	宏单元数量	Multi Function
定时调节方式	Hand Dial

环境参数

工作范围

0.1 min → 10 h

工作温度

+50°C

文档与媒体

PDF 文档

H3YN

PDF 文档

h3yn_dsheet_csm93.pdf
