点击放大查看

15-06-0080

制造商	Molex, LLC
描述	CONN RECEPT 8POS W/PANEL MOUNT Housing 4.2mm BMI recept,D/R,UL94V-2,8w Headers & Wire Housings RECPT DUAL ROW 8POS w/panel mount ears 4.20mm Pitch Mini-Fit® BMI Receptacle Housing, Dual Row with Panel Mount Ears, PA Polyamide Nylon 6/6, UL 94V-2, 8 Circuits MINIFIT BMI RCPT/PANMNT V-2 Molex MINI-FIT BMI 系列 2 行 4.2mm 节距 8 路直母面板安装压接连接器外壳
分类	连接器解决方案板对板连接器板对板连接器

对参数有疑问？问 AI 助手

商业参数

商标名	Mini-Fit BMI	零件号别名	0015060080 42474-0811
产品类别	Headers & Wire Housings	标准包装数量	1
工厂包装数量	1200

合规参数

RoHS

Compliant

电气参数

最大额定电流

12 A, 7 A

连接器类型 - 电压输入

Crimp

机械参数

颜色	Natural	深度	19.6mm
间距	0.165" (4.20mm)	宽度	17.3mm
长度	48.6mm	包装方式	Bulk
方向	直	排间距	0.165" (4.20mm)
触点形式	Female Socket	触头类型	Female Socket
引脚间距	0.165" (4.20mm)	安装类型	Panel Mount
行程角度	Straight	连接器类型	Receptacle
安装样式	Wire	排数	2
壳体材料	Nylon	端接样式	Crimp
第一触头极性	Socket (Female)	触点数	8
接触件端接	Crimp	位数	8

产品信息

备注	Contacts Not Provided	类型	Receptacle Panel Mount
连接器性别	Female	系列	42474
CAD图纸	3D CAD Model	制造商全称	Mini-Fit BMI
产品子类型	Receptacles / Sockets - Housings	电路数	8
基础产品编号	42474	输出配置	Panel Mount
适用产品/相关产品	Mini-Fit BMI Receptacle

文档与媒体

PDF 文档

15-06-0xx0,0xx1
