565-003-000-410
| 制造商 | |
| 描述 | CONN RCPT 3 WAY BLACK 22-28AWG Headers & Wire Housings 3WAY 3A RCPT (22-28) WATERPROOF HSNG BLK Conn Housing RCP 3 POS 2.5mm Crimp ST Cable Mount CONNECTOR, HOUSING, RECEPTACLE, 3POS Connector: wire-wire; 565; plug; female; PIN:3; IP67; Locking: lock |
| 分类 |
商业参数
| 标准包装数量 | 250 | ||
合规参数
| RoHS | RoHS Compliant | 海关税号 | 85369010 |
| 材料阻燃等级 | UL94V-0 | ||
电气参数
| 测试电压 | 100V | 额定电压 | 100 V |
| 最大额定电流 | 3 A | 连接器类型 - 电压输入 | w/o terminals |
机械参数
| 颜色 | Black | 间距 | :2.5mm |
| 宽度 | 11.6mm | 重量 | 0 |
| 包装方式 | Bulk | 导线线规 | 28-22 |
| 触头类型 | Female Socket | 基体材料 | PBT |
| 安装类型 | Free Hanging (In-Line) | 连接器类型 | Receptacle |
| 接触镀层 | Tin | 紧固类型 | Latch Holder |
| 安装样式 | Wire | 排数 | 1 |
| 锁定特性 | lock | 触头材料 | Phosphor Bronze |
| 包装数量 | 50 | 连接器 - 电缆 | plug |
| 端接样式 | Crimp | 第一触头极性 | Socket (Female) |
| 触点数 | 3 | 接触件端接 | Crimp |
| 位数 | 3 | 绝缘材料 - 材质 | silicone rubber |
产品信息
| SPG | 50 | 备注 | Contacts Not Provided |
| 连接器性别 | :Receptacle | 系列 | 565 |
| 产品特性 | Waterproof | 产品子类型 | Receptacles / Sockets - Housings |
| 适配器系列 | 565 | 单元数量 | 1 |
| 适用产品/相关产品 | :565 Series Crimp Contacts | ||
环境参数
| 防护等级 | IP67 | 工作温度 | - 40 C to + 105 C |
文档与媒体
相关型号
565-003-000-311
EDAC
Pin & Socket Connectors 3P 3A MALE HSNG BLK 1.3-1.7MM INSUL DIA CONN HOUSING 3POS WATERPROOF
565-200-100
EDAC Inc
CONNECTORS MODULAR Pin & Socket Connectors WIRE SEAL HOLE COVER WATERPROOFING CAP Waterproofing Cap white, 565-200-100, Edac EDAC 565 系列 防水盖, 使用于防水连接器
565-290-721
EDAC Inc
CONN SOCKET 22-28AWG WATERPROOF Headers & Wire Housings SOCKET (22-28) AWG WATERPROOF CONTACT CONTACT, PIN, 28-22AWG, CRIMP Contact; female; 22÷28AWG; 565; tinned; crimped, on cable; 3A; 10mΩ Crimp contact 3 A Female 28...22 AWG, 565-290-721, Edac
565-003-000-310
