点击放大查看
MAX232ID
| 制造商 | Texas Instruments Incorporated |
| 描述 | Dual Transmitter/Receiver RS-232 16-Pin SOIC Tube IC DUAL EIA-232 DRVR/RCVR 16SOIC MAX232ID, Line Transceiver, EIA/TIA-232-F, RS-232, V.28 2-TX 2-RX 2-TRX, 5V, 16-Pin SOIC DRIVER / RECEIVER, DUAL, RS232, 16SOIC Dual EIA-232 Driver/Receiver Interface IC RS232 SOIC-16, MAX232, MAX232ID, Texas Instruments Texas Instruments 120kbps 线路收发器, RS-232接口, 2-TX 2-RX, 5 V, 16针 SOIC封装 RS-232 Interface IC Dual EIA-232 Driver |
| 分类 |
商业参数
| 其他名称 | 296-6938-5 | 标准包装数量 | Rail / Tube |
| 标准封装名称 | SOIC | ||
合规参数
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| 欧盟RoHS | Compliant | 海关税号 | 85411000 |
| 零件状态 | :232 | 抗辐射加固 | No |
| ESD保护 | 2 | ||
电气参数
| 数据速率 | 120 Kbps | 接口 | EIA/TIA-232-F|V.28 |
| 输入信号 | Single-Ended | 信号类型 | Single-Ended |
| 输入功率 | Single | 数据速率（最大） | Point-to-Point |
| 输出电流 | 10 mA | 供电电流 | 10 |
| 驱动电路 | :Driver / Receiver | 供电电压 | 5 V |
| 供电类型 | Single | 传播延迟 | :500ns |
| 接收器迟滞 | 500mV | 输入偏置电流 | 10 |
| 最大额定电流 | Catalog | 输出电压（最大） | :0.3V |
| 逻辑电压 - VIL, VIH | 5 | 电源电压范围（典型） | Not Required V |
| 每线接收器数量 | 1 | 共模瞬态抗扰度（最小） | Industrial |
机械参数
| 宽度 | 3.91mm | 高度 | 1.58mm |
| 长度 | 9.9mm | 重量 | 0.000141 |
| 包装方式 | Tube | 封装体颜色 | :SOIC |
| 引脚样式 | Gull-wing | 安装类型 | Surface Mount |
| 引脚数 | :16 | 封装形式 | 16SOIC |
| 冷却的封装 | SOIC | 材料表面处理 | :MSL 1 - Unlimited |
| 总长度 | 10(Max) | 包装数量 | SOIC |
| 尺寸/外形 | 9.9 x 3.91 x 1.58mm | 位数 | 16 |
| 外壳尺寸-插件 | 1.5(Max) | 供应商器件封装 | 16-SOIC N |
产品信息
| 类型 | Transceiver | 双工模式 | Full |
| 已删除 | Compliant | 功能 | Line Transmitter/Receiver |
| 协议 | RS232 | 软件 | SLLS047M |
| 基本单元 | :232 | 通信接口 | RS-232 |
| 驱动器数量 | :2 | 功能框图 | alt_slls047m.gif |
| 使用的IC/零件 | View | 接收器数量 | 2 |
| 印刷电路板数量 | 16 | 发射器数量 | 2 |
| 驱动器/接收器数量 | 2/2 | 发射器/接收器数量 | 1 |
环境参数
| 测试温度 | -40 to 85 | 工作温度 | -40°C ~ 85°C |
