PT370012
| 制造商 | TE Connectivity Ltd. |
| 描述 | General Purpose Relays 3P SLDR TST BTN 12DC RELAY GEN PURPOSE 3PDT 10A 12V Electromechanical Relay 3PDT 20A 12VDC 192Ohm Plug-In Electromechanical Relay 3PDT 20A 12VDC 192Ohm Plug-In Product Highlights:PT SeriesContact Arrangement = 3 Form C, 3PDT, 3 C/OContact Current Rating = 10 Amps.Monostable Coil Magnetic SystemWithout Coil Suppression Diode PT370012 |
| 分类 |
商业参数
| 其他名称 | 6-1419111-0 | 零件号别名 | 6-1419111 6-1419111-0 |
| 产品类别 | General Purpose Relays | 标准包装数量 | 500 |
| 工厂包装数量 | 10 | ||
合规参数
| RoHS | RoHS Compliant | ||
电气参数
| 线圈类型 | Monostable | 线圈功率 | 750 mW |
| 线圈电流 | 62.5mA | 释放时间 | 10ms |
| 输入功率 | 750 | 额定电压 | 240 |
| 线圈电阻 | 192 Ohms | 浪涌电流 | 300 |
| 供电电压 | 12 V | 开关电压 | 400VAC - Max |
| Vgs(th)（最大）@ Id | 1.2 VDC | 连接器阻抗 | 3 Form C (3 CO) |
| 跳闸电流 | 20 | 最大额定电流 | 10 |
| 输出1频率 | 单稳态、直流 | 额定电流（安培） | 5 – 10, 10 – 20 |
| 绝缘电阻 | 2500 | 平均正向功率 | 750 mW |
| 集电极-发射极饱和电压（最大）@ Vge, Ic | 9 VDC | 触点额定电流 | 10 A |
| 输出源/灌电流 | 10mA @ 12V | 放电电流（最大）（8/20µs） | 10 |
| 阳极-阴极电压（Vak）（最大） | 400 | ||
机械参数
| 宽度 | 22.5 mm | 高度 | 29 mm |
| 长度 | 28 mm | 重量 | 30 g [ 1.058 oz ] |
| 包装方式 | Bulk | 绝缘类型 | 端子和线圈间 5000 V 初始浪涌耐电压 |
| 触点形式 | 3 Form C (3PDT-BM) | 高度（最大） | 25 – 30 |
| 安装类型 | Socketable | 安装样式 | SMD/SMT |
| 触头材料 | Silver Nickel | 绝缘高度 | 3 – 5.5 |
| 端接样式 | Plug In, QC - 0.110" (2.8mm) | 面板尺寸 | 28 x 22.5 x 29 mm [ 1.102 x .886 x 1.142 in ] |
| 触点数 | 3 | 初级绕组 | UL 线圈绝缘类 F |
| 接触件端接 | PCB | 介电材料 | 2500 |
| 绝缘直径 | 2.5 – 4 | 宽度/横截面 | 20 – 25 |
| 第一连接器安装类型 | 插座 | 护套（绝缘）厚度 | 3 |
产品信息
| 类型 | Ice Cube Style Relay | 系列 | PT |
| 产品特性 | Mechanical Indicator, Test Button | 继电器类型 | General Purpose |
环境参数
| 动作时间 | 15ms | 防护等级 | RTII |
| 工作温度 | -40°C ~ 70°C | 初始介电强度 | 1200 |
文档与媒体
相关型号
27E006
TE Connectivity / P&B
Relay Sockets & Hardware 2 4-POLE SLDR SOCKET SOCKET RELAY 4PDT SOLDER Conn Relay Socket SKT 4 POS Solder ST Thru-Hole Conn Relay Socket SKT 4 POS Solder ST Thru-Hole Product Highlights:SocketKHA Series, KHS Series, PT SeriesSocket Type = Panel Mount4 PolesTerminal Configuration = Solder RELAY SOCKET Socket,Relay;Solder;4;PotterandBrumfieldBrand 27E006=SOCKET,KH,14,SLG,G/T,PH
PT78730
TE Connectivity / Schrack
Relay Sockets & Hardware FOR PT3 DIN SCRE term For use with:PT SOCKET W/SCREW FOR DINRAIL Relay Socket For Use With PT3 Series Conn Relay Socket SKT 14 POS Screw ST Panel Mount SOCKET, FOR PT3 DIN SCREW TERMINAL DINsocketforPT33Prelay
27E023
te connectivity / p&b
Conn Relay Socket SKT 4 POS Solder ST Thru-Hole Relay Sockets & Hardware 4PDT PC TERM KH/KHA SOCKET PCB TERMINAL KH SERIES Conn Relay Socket SKT 4 POS Solder ST Thru-Hole Product Highlights:SocketKHA Series, KHS Series, PT SeriesNumber of Poles = 4Terminal Type = PCTerminal Length = 5.54 mm RELAY SOCKET Socket,Relay;PC;4;PotterandBrumfield;RoHSCompliant,ELVCompliant 27E023=SOCKET,KH,14,PC,PHEN,BL
27E893
te connectivity / p&b
Conn Relay Socket SKT 11 POS Screw ST Panel Mount Relay Sockets & Hardware SNAP-IN DIN MT KU Socket; Relay; Screw Term; 1-3 Pole; RoHS Compliant; ELV Compliant Conn Relay Socket SKT 11 POS Screw ST Panel Mount Product Highlights:SocketKU SeriesNumber of Poles = 1 through 3Terminal Type = ScrewWithout Grounding Provision RELAY SOCKET, DIN RAIL Socket,Relay;ScrewTerm;1-3Pole;RoHSCompliant,ELVCompliant 27E893=SOCKET,KU,11,QC,POLY,NA-
27E220
