点击放大查看

6-5535512-4

制造商	TE Connectivity Ltd.
描述	Conn Socket Strip SKT 10 POS 2.54mm Solder RA Thru-Hole Gang of Tubes .100 inch AMPMODU Receptacles CONN RECEPT 10POS .100 RT/A DUAL TE Connectivity Mod II Series 2.54mm 10 Way 2 Row Right Angle PCB Socket Through Hole Headers & Wire Housings REC 2X10P R/A T/H Conn Socket Strip SKT 10 POS 2.54mm Solder RA Thru-Hole Gang of Tubes Product Highlights:ReceptacleMod IINumber of Positions = 10Number of Rows = DualStandard ProfileSearch Keywords:AMPMODU, board to board, NIC, Network Interface Cards, PC Cards, MIL-C-55032, MIL-C-24519, pcb connectors, wire to board, signal, BOARD-BOARD CONNECTOR RECEPTACLE, 10WAY, 2ROW Receptacle10waysocketAmpModu AMPMODU 10 Position Dual Row 2.54 mm Pitch Right Angle MOD II Receptacle TE Connectivity AMPMODU Mod II 系列 2行 10路直角 2.54mm节距通孔印刷电路板插座 10 MODII HORZ DR CE EESS .100
分类	连接器解决方案板对板连接器板对板连接器

对参数有疑问？问 AI 助手

商业参数

商标名	AMPMODU	产品类别	Headers & Wire Housings
标准包装数量	Rail / Tube	工厂包装数量	45

合规参数

RoHS

Lead free / RoHS Compliant

海关税号

85369010

电气参数

最大额定电流

机械参数

颜色	Black	间距	2.54 mm
重量	0.001	包装方式	Tube
排间距	0.100" (2.54mm)	端接方式	Solder
触头类型	Female Socket	柱间距	:7.87mm
安装类型	Through Hole, Right Angle	连接器类型	Receptacle
接触镀层	Gold Over Nickel	排数	2
触头材料	Phosphor Bronze	壳体材料	Polycyclohexylenedimethylene Terephthalate (PCT)
端接样式	Through Hole	触点数	10
接触件端接	:Through Hole Right Angle	位数	10
接触镀层厚度	30µin (0.76µm)

产品信息

类型	Socket Strip	连接器性别	SKT
系列	Mod II	产品子类型	Receptacles / Sockets - PCB
加载位置数	All

环境参数

工作温度

- 55 C to + 125 C

文档与媒体

在线文档

6-5535512-4

在线文档

6-5535512-4?RQPN=6-5535512-4
