6-103644-9

点击放大查看

6-103644-9

制造商
TE Connectivity Ltd.
描述Conn IDC Connector RCP 20 POS 2.54mm IDT ST Cable Mount Individual .100 AMPMODU Headers, Housings & Contacts CONN RCPT 20POS LATCH .100 GOLD Headers & Wire Housings 20 MTE RCPT SR LATCH .100CL .100 AMPMODU Headers, Housings & Contacts Product Highlights:HousingPreloadedNumber of Positions = 20Housing Type = ReceptacleContact Type = ReceptacleSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE 20 MTE RCPT SR LATCH .100CL
分类
连接器解决方案板对板连接器板对板连接器
对参数有疑问？问 AI 助手

商业参数

商标名AMPMODU标准包装规格11
产品类别Headers & Wire Housings标准包装数量Rail / Tube

合规参数

RoHSLead free / RoHS Compliant标准CSA LR7189, UL E28476
材料阻燃等级UL 94V-0

电气参数

输入电阻5000连接器阻抗刺破式压接 (IDC), 压接
最大额定电流3 A保护额定电压（VPR）600 V

机械参数

颜色Black间距2.54 mm
锁定类型Latch包装方式Tube
导线类型Discrete or Ribbon Cable壳体颜色黑色
导线线规22-26 AWG排间距2.54 mm
端接方式IDT触头类型Female Socket
第二连接器With安装类型Free Hanging (In-Line)
连接器类型Receptacle接触镀层Gold Over Nickel
紧固类型Latch Lock安装样式Wire
排数1插入件材料磷青铜
操作力Standard触头材料Phosphor Bronze
壳体材料Thermoplastic包装数量11
电缆端接方式IDC端接样式Crimp
第一触头极性Socket (Female)触点数20
绝缘直径.76 – 1.37 mm位数20
安装孔直径带有典型触点布局同轴
接触镀层厚度15µin (0.38µm)

产品信息

备注带状电缆带缺口把手 22-28 AWG, 气动终结器的最大绝缘直径为 1.14 [0.045]。类型IDC Connector
连接器性别RCP系列AMPMODU MTE
产品特性Closed End产品子类型Receptacles / Sockets - Housings
