350588-1

点击放大查看

350588-1

制造商
TE Connectivity Ltd.
描述Conn Power HDR 15 POS 6.35mm Solder ST Thru-Hole 15 Terminal 1 Port Universal MATE-N-LOK Connectors CONN HEADER 15POS VERT .250 TIN Pin & Socket Connectors 15P PIN HEADER 92VO Conn Power HDR 15 POS 6.35mm Solder ST Thru-Hole 15 Terminal 1 Port Product Highlights:HeaderUniversal MATE-N-LOKNot CompactPCI6.35 x 6.35 mm Centerline, MatrixNumber of Circuits = 15Search Keywords:wire to wire, wire to board, Lighting Interconnection, soft shell, pcb connectors, power, discrete wire, crimp, PWRSIGALLP 15P UMNL PIN HDR ASSY V2 NATL
分类
工具与焊接解决方案压接钳、压接机、压力机压接钳
对参数有疑问？问 AI 助手

商业参数

产品类别Pin & Socket Connectors标准包装数量Bulk
工厂包装数量1

合规参数

RoHSLead free / RoHS CompliantUL等级获得认可
零件状态E28476无铅定义Wave solder capable to 240°C / Wave solder capable to 260°C / Wave solder capabl
标准编号ULRoHS/ELV合规状态RoHS compliant / ELV compliant
UL阻燃等级UL 94V-2认证机构标志是
材料阻燃等级UL 94V-2

电气参数

电压600.0额定电压600 V
供电电压600最大额定电流19
最小供电电压600VAC输出高/低电流No

机械参数

颜色Natural间距6.35 mm
高度14.73 mm密封型Not Sealed
包装方式Bulk排间距0.250" (6.35mm)
端接方式Solder触头类型Pin
安装类型Through Hole连接器类型Header
接触镀层Tin紧固类型Positive Lock
安装样式Through Hole引脚数15
排数3封装形式Receptacle
连接器样式Plug触头材料Phosphor Bronze
壳体材料Nylon包装数量50
面板安装类型通孔 - 焊接主要材料Phosphor Bronze
端接样式Solder第一触头极性Pin (Male)
触点数15接触件端接Through Hole
位数15排距 - 配合6.35
中心触点表面处理6.35兼容外壳尺寸（如TM-700等）与插头护套插接（使用插座端子）
安装孔直径带有接触件表面处理 - 配合预镀锡
典型触点布局Matrix端子柱长度5.97
接触镀层厚度2.54 µm [ 100 µin ]恢复壁厚3.18
触点材料 - 配合Pre-Tin静电放电屏蔽不带
护套（绝缘）厚度1.27 µm [ 50 µin ]

产品信息

类型Power连接器性别HDR
系列Universal MATE-N-LOK可密封No
产品子类型Connector端口数1 Port
其他规格Printed Circuit Board应用细节Power
装配配置Without加载位置数All

环境参数

插拔次数With测试温度标准件 - 非灼热丝
工作温度-40 – 105 °C [ -40 – 221 °F ]封装热阻1.57 mm [ .062 in ]

文档与媒体

在线文档
350588-1?RQPN=350588-1

相关型号
