1658620-2

点击放大查看

1658620-2

制造商
TE Connectivity Ltd.
描述Conn IDC Connector F 14 POS 2.54mm IDT RA Cable Mount Ribbon Cable Connectors (AMP-LATCH) CONN IDC SOCKET 14POS 15 GOLD Receptacle 14 way IDC Amp-Latch Headers & Wire Housings MLTRY PLRZD RECPT 14 NOVO Conn IDC Connector F 14 POS 2.54mm IDT RA Cable Mount Product Highlights:Connector Type = NOVONumber of Positions = 14ReceptacleMating Polarization Method = MilitaryWith Mating PolarizationSearch Keywords:input/output, paddleboard, paddle board CONNECTOR,RECEPTACLE,NOVA,AMP-LATCH,14POSITION,WITHMATINGPOLARIZATION TE Connectivity AMP-LATCH Novo 系列 2行 14路 2.54mm节距 母 IDC 连接器 , 电缆安装 14 NOVO MIL 15DP, LEAD FREE
分类
连接器解决方案板对板连接器板对板连接器
对参数有疑问？问 AI 助手

商业参数

商标名AMP-LATCH产品类别Headers & Wire Housings
标准包装数量Trays工厂包装数量1080

合规参数

RoHSLead free / RoHS CompliantUL等级获得认可
无铅定义Not relevant for lead free processUL档案号E28476
CSA档案号LR 7189标准编号CSA, UL
RoHS/ELV合规状态RoHS compliant, ELV compliant材料阻燃等级UL 94V-0

电气参数

额定电压250 V ac供电电压250
接触电阻15 mohm输入电阻5000
连接器阻抗刺破式压接 (IDC)最大额定电流1A
最小供电电压250VAC连接器类型 - 电压输入音叉

机械参数

颜色Black深度6.09 mm
间距2.54 mm宽度6.1 mm [ .2402 in ]
高度15.97 mm长度22.35 mm [ .8799 in ]
底座类型不带包装方式Tube
导线类型Ribbon Cable壳体颜色黑色
出线方向Without电缆类型带状电缆
导线线规26-28 AWG方向直
排间距0.100" (2.54mm)端接方式IDT
触头类型Female Socket极化Military
第二连接器Without外壳颜色Black
安装类型No电缆端类型Without
连接器类型NOVO接触镀层Gold Over Palladium Nickel Over Nickel|Gold Over Nickel
法兰特征否安装样式Cable
排数2驱动力不带
插入件材料磷青铜触头材料Phosphor Bronze
壳体材料Thermoplastic总长度22.35 mm
安装特性Without包装数量60
面板安装类型通孔 - 焊接尺寸/外形.08 – .15 mm², 158 – 296 CMA, 28 – 26 美国线规
端接排数IDC电缆端接方式IDC
端接样式IDC第一连接器类型插针接头
第一触头极性Socket (Female)配接方向With
触点数14绝缘材料 - 类型.787 – .94 mm [ .031 – .037 in ]
位数14触头长度-柱信号（数据）
安装孔直径带有中心触点材料2.54 x 2.54 [.100 x .100]
接触件表面处理 - 配合锡接触镀层厚度15µin (0.38µm)

产品信息

备注Receptacle can be used in applications requiring non-polarization, as well as m类型IDC Connector
连接器性别F系列AMP LATCH Novo
产品特性Feed Through极性带有
产品子类型Receptacles / Sockets - Housings连接类型Ribbon Cable
带调制解调器控制YesDigiKey可编程不带
应用细节Wire-to-Board
