1-87175-4

制造商	TE Connectivity Ltd.
描述	Conn Housing RCP 6 POS 2.54mm Crimp ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN HOUSING 6POS .100 LOCKING Headers & Wire Housings CONN HOUSING 6 POS SINGLE ROW Conn Housing RCP 6 POS 2.54mm Crimp ST Cable Mount Product Highlights:Receptacle HousingWire Termination Type = CrimpNumber of Positions = 6Housing Type = ReceptacleNumber of Rows = SingleSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE LOCKINGCLIP,AMPMODU,RECEPTACLE,6POSITIONSINGLEROW 06 LOCKING CLIP HSG SR .100CL
分类	连接器解决方案矩形连接器高可靠性矩形连接器

对参数有疑问？问 AI 助手

商业参数

商标名	AMPMODU	产品类别	Headers & Wire Housings
标准包装数量	Bulk	工厂包装数量	1

合规参数

RoHS	Lead free / RoHS Compliant	标准编号	CSA LR7189, UL E28476
材料阻燃等级	UL 94V-0

电气参数

额定电压	250 VAC	供电电压	250 VAC
接触电阻	12 mΩ	输入电阻	5000
连接器阻抗	压接	最大额定电流	3 A
最小供电电压	250VAC	保护额定电压（VPR）	750 V

机械参数

颜色	Black	深度	17.78 mm
间距	2.54 mm	高度	4.44 mm
长度	15.54 mm [ .61 in ]	锁定类型	不带
包装方式	Bulk	壳体颜色	黑色
导线线规	22-30 AWG	排间距	2.54 mm
触头类型	Female Socket	外壳颜色	Black
安装类型	Straight	连接器类型	Receptacle
排数	1	插入件材料	磷青铜
壳体材料	Polyester	总长度	15.64 mm
包装数量	1	主要材料	InterconnectSystem
端接样式	Crimp	第一触头极性	Socket (Female)
触点数	6	接触件端接	Crimp
位数	6	安装孔直径	不带
典型触点布局	同轴

产品信息

备注	Contacts Not Provided	类型	Housing
连接器性别	RCP	系列	AMPMODU Locking Clip
制造商全称	AMPMODU	产品子类型	Connectors
其他规格	否	应用细节	Board-to-Board

环境参数

测试温度

标准部件 - 非辉光导线

工作温度

- 65 C to + 105 C
