点击放大查看
1-1634219-2
| 制造商 | TE Connectivity Ltd. |
| 描述 | Conn D-Subminiature PIN 15 POS 2.77mm Solder ST Thru-Hole 15 Terminal 1 Port Tray D-Sub Standard Connectors PLUG 15 POS VERT GOLD Standard Board Mount Connectors CONN D-SUB PLUG 15POS VERT GOLD 15 way D-plug plus lock & insert 15wayD-plugpluslock&insert TE Connectivity Amplimite HD-20 系列 2.77mm 节距 15 路 直向 通孔安装 PCB D-sub 连接器 插头 15w D plg W B/L & 4-40 inserts 15u" gold |
| 分类 |
商业参数
| 产品类别 | D-Sub Standard Connectors | 标准包装数量 | Bulk |
| 工厂包装数量 | 1 | ||
合规参数
| RoHS | RoHS Compliant | 标准 | UL E28476 |
| 抗辐射加固 | No | 无铅定义 | Wave solder capable to 240°C, Wave solder capable to 260°C, Wave solder c |
| 认可国家 | UL E28476 | RoHS/ELV合规状态 | RoHS compliant, ELV compliant |
| 材料阻燃等级 | UL 94V-0 | ||
电气参数
| 接地方式 | Without | 额定电压 | 250V |
| 连接器阻抗 | 螺纹插针，4-40 UNC, 螺纹插针，4-40 UNC | 最大额定电流 | 3A |
| 最小供电电压 | 250VDC | ||
机械参数
| 颜色 | Black | 深度 | 12.55mm |
| 间距 | 2.77 mm | 宽度 | 12.1mm |
| 高度 | 12.6 mm | 长度 | 39.2mm |
| 密封型 | No | 外形尺寸(长x宽) | 2 |
| 包装方式 | Tray | 壳体颜色 | 黑色 |
| 外壳尺寸 | 2 | 方向 | 直 |
| 端接方式 | Solder | 触头类型 | Signal |
| 标称内径 | .6 | 外壳表面处理 | 镍 |
| 第二连接器 | With | 安装类型 | Through Hole |
| 外壳镀层 | Tin | 连接器类型 | Plug, Male Pins |
| 接触镀层 | Gold | 法兰特征 | Housing/Shell (4-40) |
| 接地类型 | Without | 安装样式 | Through Hole |
| 排数 | 2 | 外壳材料（壳体） | Steel |
| 电路板厚度 | 0.063 [1.60] | 连接器样式 | D-Sub |
| 插入件材料 | 黄铜 | 锁定特性 | Threaded Insert, 4-40 UNC |
| 触头材料 | Brass | 壳体材料 | Thermoplastic |
| 总长度 | 39.2 mm | 安装特性 | 板锁 |
| 包装数量 | 70 | 面板安装类型 | Without |
| 尺寸/外形 | 39.2 x 12.1 x 12.55mm | 接地凹痕 | With |
| 端接样式 | Through Hole | 连接器颜色 | None |
| 触点数 | 15 | 位数 | 15 |
| 外壳尺寸-插件 | Full Metal | 安装孔直径 | 3.1 |
| 外壳材料及表面处理 | Steel, Nickel Plated | 端子柱长度 | 4.00 [0.157] |
| 接触镀层厚度 | 15µin (0.38µm) | 外壳与棱镜材料 | 否 |
| 后壳材料及镀层 | 镍 | 外壳尺寸，连接器布局 | 2 (DA, A) |
产品信息
| 类型 | D-Subminiature | 连接器性别 | PIN |
| 系列 | HD-20 | 产品特性 | Board Lock, Grounding Indents |
| 可密封 | 否 | 制造商全称 | AMP |
| 预装 | 是 | 产品子类型 | 连接器 |
| 端口数 | 1 Port | 其他规格 | 4-40 UNC 螺纹插件、板锁 |
环境参数
| 工作温度 | -55°C ~ 105°C | 封装热阻 | 1.57 mm [ .062 in ] |
