点击放大查看
KMF1.1241.11
| 制造商 | |
| 描述 | Power Entry Module Filtered M 3 POS 250VAC 4A Switch/Fuse ST 1 Port KMF G-STECKER-KOMBI MIT FILTER 4A MOD PWR STD FILTER 4A 1PL QC PNL AC Power Entry Modules POWER ENTRY MOD 2A 10A/250VAC No/Drawer INLET FILTER, IEC, C14, KMF, 4A POWER ENTRY MODULE, PLUG, 4A KMFPOWERENTRYMODULEW.FILTER4A Power inlet with filter 4 A 250 VAC, KMF1.1241.11, Schurter |
| 分类 |
商业参数
| 最小起订量 | 20 | 产品 | Inlets |
| 单位包装 | 20 | 产品类别 | AC Power Entry Modules |
| 标准包装数量 | Bulk | 工厂包装数量 | 20 |
合规参数
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| 海关税号 | 85363090 | 认证机构 | :CCC |
| 材料阻燃等级 | UL 94 V-0 | ||
电气参数
| 电流 | 4A | 电压 | 125/250VAC |
| 电容 | :0.047µF | 滤波器类型 | General Purpose |
| 额定电压 | 250 VAC | 开关功能 | Switched |
| 电感量范围 | :1.6mH | 最大额定电流 | :4A |
| 最小输入电压 | 250 Vac | 漏电流（IS(off)）（最大） | :500µA |
机械参数
| 重量 | 2.045890 oz | 交流输出口 | :1 |
| 端接方式 | Solder Lug | 安装类型 | Snap-In |
| 连接器类型 | IEC/EN 60320-1/C14|UL 498|CSA C22.2 | 安装样式 | Snap In |
| 保险丝座类型 | Sold Separately | 壳体材料 | Thermoplastic |
| 端接样式 | Quick Connect | 触点数 | 3 |
| 接触件端接 | :Quick Connect | 第一连接器安装类型 | :Panel |
产品信息
| 类型 | Filtered | 带保险丝 | Yes |
| 连接器性别 | :Plug | 系列 | KMF |
| 产品特性 | Fuse Holder, Shielded, Switch On/Off, Non-Illuminated | ||
环境参数
| 工作温度 | - 25 C to + 85 C | ||
