点击放大查看
19216-0003
| 制造商 | Molex, LLC |
| 描述 | Terminals MULTI-LOCK 16-14AWG CONN MULTI-LOCK 14-16AWG BLUE |
| 分类 |
对参数有疑问？问 AI 助手
商业参数
| 产品 | Splices | 零件号别名 | 0192160003 ML-1614 |
| 产品类别 | Terminals | 标准包装数量 | 1 |
| 工厂包装数量 | 500 | ||
合规参数
| RoHS | RoHS Compliant | ||
电气参数
| 额定电压 | 600 V | ||
机械参数
| 颜色 | Blue | 长度 | 20.1 mm |
| 材料（通用） | Brass | 包装方式 | Bag |
| 绝缘类型 | Insulated | 导线线规 | 16-14 |
| 端接方式 | IDC | 安装类型 | Wire |
| 端子类型 | Inline, Tap | 接触镀层 | Tin |
| 线束直径 | 2.5 mm | 触头材料 | Brass |
| 端接样式 | Crimp | 绝缘材料 - 类型 | Polypropylene |
| 进线口数 | 2 | ||
产品信息
| 类型 | Multi-Lock | 连接器性别 | Female |
| 系列 | 19216 | 产品特性 | Hinged Lids |
