14-56-2022
| 制造商 | Molex, LLC |
| 描述 | CONN IDC 2POS .100 GOLD 24AWG Headers & Wire Housings CGrid SL IDT Opt G 15 SAu 2Ckt Conn IDC Connector F 2 POS 2.54mm IDT ST Cable Mount Tube |
| 分类 |
商业参数
| 商标名 | C-Grid, SL | 零件号别名 | 0014562022 A-70400-0666 |
| 产品类别 | Headers & Wire Housings | 标准包装数量 | 1 |
| 工厂包装数量 | 3120 | ||
合规参数
| RoHS | RoHS Compliant | ||
电气参数
| 额定电压 | 250 V | 最大额定电流 | 3 A |
机械参数
| 颜色 | Black | 间距 | 0.100" (2.54mm) |
| 包装方式 | Tube | 导线类型 | Discrete or Ribbon Cable |
| 导线线规 | 24 AWG | 触头类型 | Female Socket |
| 安装类型 | Free Hanging (In-Line) | 连接器类型 | Receptacle |
| 接触镀层 | Gold | 紧固类型 | Latch Lock |
| 安装样式 | Cable | 排数 | 1 |
| 触头材料 | Phosphor Bronze | 壳体材料 | Polyester Alloy |
| 电缆端接方式 | IDC | 端接样式 | IDC |
| 第一触头极性 | Socket (Female) | 触点数 | 2 |
| 位数 | 2 | 接触镀层厚度 | 15µin (0.38µm) |
产品信息
| 系列 | 70400 | 产品特性 | Closed End |
| 产品子类型 | Receptacles / Sockets - Housings | ||
文档与媒体
相关型号
0705430001
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder ST Thru-Hole Tube CONN HEADER 2POS .100 VERT GOLD
0701070106
molex
Conn Housing F 2 POS 2.54mm Crimp ST Bag SL WTW CONN SR OPT D 2POS
0705510001
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder RA Thru-Hole Tube SL R/A LATCH HEADER TIN 2CKT
0701070001
molex
Conn Housing F 2 POS 2.54mm Crimp ST Bag Conn Housing F 2 POS 2.54mm Crimp ST Cable Mount Bag CONN HOUSING MALE 2POS .100 Connector: wire-wire; SL; plug; male; w/o terminals; PIN:2; 2.54mm
0705550036
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder RA Thru-Hole Tube CONN HEADER 2POS .100 R/A 15AU
0705530001
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder RA Thru-Hole Tube CONN HEADER 2POS .100 R/A GOLD
0705530106
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder RA Thru-Hole Tube CONN HEADER 2POS .100 R/A 30AU
0623003000
molex
RIBBON CABLE HAWK W/O BREAK-OFF STATION HAWK Ribbon Cable Terminator For SL Without Break-Off RIBBON CABLE HAWK
0705450036
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder ST Thru-Hole Tube CONN HEADER 2POS .100 VERT 15AU
0705430106
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder ST Thru-Hole Tube CONN HEADER 2POS .100 VERT 30AU
0705550001
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder RA Thru-Hole Tube CONN HEADER 2POS .100 R/A TIN
0705430036
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder ST Thru-Hole Tube CONN HDR VERT 2POS .100 TIN
0705530036
molex
Conn Shrouded Header HDR 2 POS 2.54mm Solder RA Thru-Hole Tube CONN HDR RT ANG 2POS .100 TIN
68301-1054
Molex
Headers & Wire Housings 2.54MM BREAKAWAY Vertical 2 CKT CONN HEADER 2POS .100" VERT TIN
0015913024
