点击放大查看
PIC32MX250F128D-I/PT
| 制造商 | Microchip Technology Inc. |
| 描述 | 32-bit Microcontrollers - MCU 32B 128KB FL 32KB RAM 40MHz 44 Pin IC MCU 32BIT 128KB FLASH 44TQFP PIC32MX250F128D-I/PT, 32 bit Microcontroller PIC 40MHz 131kb Flash, 32kb RAM, USB I2C SPI 44-Pin TQFP MCU 32-bit PIC32 PIC RISC 128KB Flash 2.5V/3.3V 44-Pin TQFP Tray IC, 32BIT MCU, PIC32, 40MHz, TQFP-44 IC, MCU, 32BIT, 128KB FLASH, 44TQFP PIC microcontroller; SRAM:32kB; 40MHz; TQFP44; 2.3÷3.6V Microcontroller 32 Bit TQFP-44, PIC32MX250F128D-I/PT, Microchip Microchip PIC32MX 系列 32 bit PIC MCU, 40MHz, 131 kB ROM 闪存, 32 kB RAM, 1xUSB, 44针 TQFP封装 PIC32MX 128K TQFP44 105°C |
| 分类 |
商业参数
| 其他名称 | PIC32MX250F128DIPT | 标准包装数量 | 160 |
合规参数
| RoHS | Compliant | SVHC | :No SVHC (20-Jun-2013) |
| 海关税号 | 85423190 | 抗辐射加固 | No |
电气参数
| 转速 | 40MHz | 定时器 | 5 x 16 bit |
| 存储器 | 128kB | RAM 大小 | 32K x 8 |
| 内核大小 | 32-Bit | 核心类型 | PIC |
| 频率 | 40 MHz | 接口 | :I2C, LIN, SPI, UART, USB |
| 时钟速率 | 40 MHz | 存储器容量 | 32 KB |
| I/O 数量 | 33 | 额定电压 | 2.3 → 3.6 V |
| 时钟频率 | :40MHz | 数据转换器 | A/D 13x10b |
| 最大频率 | 40MHz | DAC数量 | 5 |
| 振荡器类型 | Internal | 供电电压 | 2.3 V to 3.6 V |
| 分辨率（位） | 10bit | 通道数量 | 0 |
| 程序存储器大小 | 128KB (128K x 8) | 程序存储器类型 | FLASH |
| ADC/DAC 数量 | 13 | 最小供电电压 | 2.3 V |
| 频率（中心/带宽） | 16bit | 供电电压 (Vcc/Vdd) | 2.3 V ~ 3.6 V |
机械参数
| 宽度 | 10mm | 高度 | 1.05mm |
| 长度 | 10mm | 重量 | 0.001 |
| 包装方式 | Tray | 安装类型 | Surface Mount |
| 安装样式 | SMD/SMT | 引脚数 | :44 |
| 封装形式 | 44-TQFP | 冷却的封装 | TQFP |
| 材料表面处理 | :MSL 3 - 168 hours | 包装数量 | 160 |
| 尺寸/外形 | 10 x 10 x 1.05mm | 位数 | 44 |
| 供应商器件封装 | 44-TQFP (10x10) | 核心数/总线宽度 | 32bit |
| 脉冲宽度失真（最大） | 5 | ||
产品信息
| SPG | 160 | USB | 1 |
| 类型 | PIC microcontroller | 系列 | PIC32MX |
| 产品特性 | DMA | 片内RAM（通道数×位宽） | Yes |
| 外设 | Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT | 架构 | RISC |
| 连接性 | I²C, IrDA, LIN, PMP, SPI, UART/USART, USB OTG | 可编程性 | Yes |
| 核心处理器 | MIPS32® M4K™ | 内置振荡器 | 32kHz, 8MHz |
| 单元数量 | 1 | 定时器数量 | 5 |
| 控制器系列 | :PIC32 | 射频系列/标准 | PIC32 |
| 宏单元数量 | 2 | ||
环境参数
| 工作温度 | -40°C ~ 85°C | 结工作温度 | 85C |
