FFB0912EHE

制造商	Delta Electronics, Inc.
描述	DC Fan Ball Bearing 12V 1A 12W 4800RPM 110.18CFM 55dB Flange Mount 12V DC FAN 92X92X38 MM
分类	硬件与散热解决方案直流风扇鼓风机

对参数有疑问？问 AI 助手

商业参数

其他名称

603-1426

标准包装数量

合规参数

RoHS	Lead free / RoHS Compliant	欧盟RoHS	Compliant
抗辐射加固	No

电气参数

噪声	55 dB(A)	转速	Clockwise
频率	Not Required Hz	输入范围	7V to 13.8V
噪声系数	55 dB	功率（瓦）	12.0W
额定功率	12 W	电压范围	7 ~ 13.8VDC
额定电压	12VDC	输出电流	1
供电电流	1 A	最大额定电流	1A

机械参数

RPM	4800 RPM	深度	92 mm
高度	38 mm	重量	0.436 lb (197.77g)
风量	110.2 CFM (3.12m³/min)	直径	Not Required mm
风扇类型	Tubeaxial	端接方式	Lead Wire
轴承类型	Ball	安装类型	Flange Mount
安装样式	Flange	静压	0.665 in H2O (165.6 Pa)
壳体材料	Plastic	总长度	92 mm
刀片材料	Plastic	框架材料	Plastic
最大压力	0.665inH2O	尺寸/外形	Square - 92mm L x 92mm H x 38mm W

产品信息

类型

DC Fan

环境参数

额定寿命

70000 hrs @ 40°C

工作温度

14 ~ 140°F (-10 ~ 60°C)

文档与媒体

PDF 文档

FFB 92x92x38MM
