点击放大查看
CWA4810E
| 制造商 | Custom Sensors & Technologies (CST) |
| 描述 | Solid State Relays - Industrial Mount 0.15-10A 18-36VAC RELAY SSR PANEL MOUNT Solid State Relay Control Voltage: 18-36 VAC Load Current: 10 Amps Load Voltage: 48-660 VAC Output Configuration: 1A SPST-NO Mounting: Panel Mount |
| 分类 |
商业参数
| 产品类别 | Solid State Relays - Industrial Mount | 标准包装数量 | 20 |
合规参数
| RoHS | RoHS Compliant | ||
电气参数
| 输出端 | SCR | 电路 | SPST-NO (1 Form A) |
| 指示器 | yes | 输出类型 | AC, Zero Cross |
| 负载电流 | 10A | 开启时间 | 1/2 Cycle |
| 负载电压 | 48 ~ 660 V | 浪涌电流 | 380 |
| 输入阻抗 | 1 k ohm | 关断延迟时间 | 1/2 Cycle |
| 最大交流电压 | 660 | 供电电压 | 18 VAC to 36 VAC |
| 电容范围 | 8 pF | 钳位电压 | 1200 |
| 连接器阻抗 | Screw Type, Finger Proof; Output: 8-32, Combo Drive; Input: 6-32, Combo Drive | 断态电压 | 2 Vrms |
| 最大额定电流 | 10 A | 绝缘电阻 | 10^9 Ohm |
| 最小输入电压 | 18 ~ 36VAC | 最小供电电压 | 48 VAC to 660 VAC |
| 集电极-发射极饱和电压（最大）@ Vge, Ic | 1.3 | 输入偏置电流（最大） | 24mA@24Vrms |
| 差分 - 输入:输出 | 4000 Vrms | 通态峰值电压（最大） | 18 Vrms |
| 漏电流（IS(off)）（最大） | 1 | ||
机械参数
| 扭矩 | Output: 20 in lb (2.2Nm); Input: 10 in lb (1.1Nm) | 重量 | 3.0 oz. (86.5g) |
| 包装方式 | Bulk | 安装类型 | Chassis Mount or Panel Mount |
| 安装样式 | Panel | 封装形式 | Hockey Puck |
| 端接样式 | Screw | 外壳尺寸-插件 | Intergrated Removable Fingerproof Cover |
| 线路侧导线/螺柱尺寸 | Output: 2 x AWG 8 (3.8mm); Input: 2 x AWG 12 (2.5mm) | ||
产品信息
| 类型 | Relays | 系列 | CW 24 |
| 继电器类型 | Relay | 产品子类型 | Industrial Mount |
| 卡标准 | Solid State Relay | 控制/显示类型 | 18-36 VAC |
| 其他规格 | 0.5 | 输出配置 | 1A NO |
环境参数
| 机械寿命 | Obsolete | 存储接口 | -40 to 125°C |
| 热阻 | 0.35 | 工作温度 | -40 to 80°C |
