点击放大查看

CC2450W3V

制造商	Custom Sensors & Technologies (CST)
描述	Solid State Relays - Industrial Mount 4-32VDC 24-280VAC 50A 4Pin Screw Term RELAY SSR DUAL 50A ZERO PNL MNT 50A rms Panel Mount, Zero Voltage Solid State Relay, 280V rms Relay SSR 10mA 32V DC-IN 50A 280V AC-OUT 8-Pin Relay;SSR;Cur-Rtg50A;Ctrl-V4-32VDC;Vol-Rtg24-280VAC;Panel;FourPinScrew Solid State Relay Control Voltage: 4-32 VDC Load Current: 50 Amps Load Voltage: 24-280 VAC Output Configuration: 2A DPST-NO Mounting: Panel Mount
分类	工业电源组件和继电器固态继电器固态继电器

商业参数

其他名称	CC1691	产品类别	Solid State Relays - Industrial Mount
标准包装数量	20

合规参数

RoHS

RoHS Compliant By Exemption

电气参数

输出端	SCR	电路	DPST (2 Form A)
输出类型	AC, Zero Cross	负载电流	50A
开启时间	1/2 cycle	负载电压	24 ~ 280 V
额定电压	280VAC	供电电压	4 VDC to 32 VDC
电池组电压	24 V ac	最大额定电流	50 A
最小输入电压	4 ~ 32VDC	最小供电电压	24 VAC to 280 VAC
关态电流（最大）	1 mA	静态电流（最大）	0.15 A rms
驱动电压（最大Rds On，最小Rds On）	18VDC

机械参数

深度	45.72mm	高度	36.2mm
长度	58.42mm	包装方式	Bulk
安装类型	Chassis Mount or Panel Mount	端子类型	Screw
安装样式	Panel	封装形式	Hockey Puck
端接样式	Screw

产品信息

类型	Relays	系列	Evolution Dual
继电器类型	Relay	开关类型	Zero Voltage
制造商全称	CCSeries	产品子类型	Industrial Mount
卡标准	Solid State Relay	控制/显示类型	4-32 VDC
输出配置	2A DPST-NO

文档与媒体

Declaration of Conformity

Dual Solid State Relay Brochure

Evolution Dual Series

ev_dual.pdf
