7282-4PG-3ES

制造商	Switchcraft, Inc.
描述	Standard Circular Connector MINI-CON PAN MT #20 SOLDER Conn Field Installable PIN 4 POS Solder Cup ST Panel Mount 4 Terminal 1 Port CONN RCPT 4POS PNL MNT PIN MINI-CONPANELMT#20SOLDER
分类	连接器解决方案圆形连接器标准圆形连接器

商业参数

标准包装数量

工厂包装数量

合规参数

RoHS

Lead free / RoHS Compliant

欧盟RoHS

Supplier Unconfirmed

电气参数

额定电压

600V

最大额定电流

4.8 A to 13 A

机械参数

深度	20.6	高度	23.5
直径	23.5	包装方式	Bulk
出线方向	No	导线线规	18-16
方向	Keyed	端接方式	Solder Cup
触头类型	4Signal	安装类型	Panel Mount
连接器类型	Receptacle, Male Pins	接触镀层	Gold Over Nickel
紧固类型	Bayonet Lock	安装样式	Panel
触头材料	Brass	端接样式	Solder Cup
第一触头极性	PIN	触点数	4
位数	4	外壳材料及表面处理	Nylon

产品信息

类型	Field Installable	系列	Mini-Con-X
产品子类型	Connectors

环境参数

防护等级

Weathertight

工作温度

-40°C ~ 115°C

文档与媒体

Mini-Con-X Connectors

相关型号

暂无图片

6293SP

Conxall / Switchcraft

Standard Circular Connector MINI-CON GASKET-SPC MINI-CON-X GASKET - SPECIAL MINI-CON-XGASKET-SPECIAL

¥2.9304

详情

6282-4SG-3DC
