9164-4500PL

制造商	3M Company
描述	Conn Socket Strip SKT 64 POS 2.54mm Solder ST Thru-Hole .100" Ã .100" Centerbump Polarization with Straight Solder Tails, 20 - 64 contacts CONN SOCKET 64POS .100" STR GOLD Headers & Wire Housings POLARIZED BDMNT SCKT 64 PIN
分类	连接器解决方案板对板连接器板对板连接器

对参数有疑问？问 AI 助手

商业参数

零件号别名

54745226301 JE150318895

标准包装数量

Bulk

合规参数

RoHS

Lead free / RoHS Compliant

电气参数

最大额定电流

1 A

机械参数

颜色	Gray	间距	2.54 mm
包装方式	Bulk	排间距	0.100" (2.54mm)
端接方式	Solder	触点形式	Female Socket
触头类型	Female Socket	引脚间距	0.100" (2.54mm)
安装类型	Through Hole	连接器类型	Receptacle
接触镀层	Gold Over Nickel	排数	2
触头材料	Copper Alloy	壳体材料	Polyester
端接样式	Through Hole	第一触头极性	Socket (Female)
触点数	64	位数	64
接触镀层厚度	12µin (0.30µm)	每排/每行位置数	All

产品信息

类型	Socket Strip	连接器性别	SKT
系列	9100	产品特性	Polarizing Key
主要用途	Polarizing Key	产品子类型	Receptacles / Sockets - Housings
输出配置	Through Hole	加载位置数	All

环境参数

工作温度

- 55 C to + 105 C
