点击放大查看

8520-4500PL

制造商	3M Company
描述	Conn Socket Strip SKT 20 POS 2.54mm Solder ST Thru-Hole .100" Ã .100" Centerbump Polarization with Straight Solder Tails, 10 - 64 contacts CONN SOCKET PCB VERT 20POS .1" 3M 2.54mm 20 Way 2 Row Straight PCB Socket Through Hole Socket Strip Headers & Wire Housings 20P STRT PLRZD SKT RECEPTACLE, THT, VERTICAL, 2.54MM, 20WAY BOARD TO BOARD, RECEPTACLE, 20POS, 2ROW PolarizedBoardmountSocket(20pos).100centerlinestraightsoldertails Socket; IDC; female; PIN:20; THT; 1.27mm; Contacts ph:2.54mm Socket; IDC; female; PIN:20; straight; THT; gold plated; 3A; 2.54mm 3M 8500 系列 2行 20路直 2.54mm节距通孔印刷电路板插座, 插座板
分类	连接器解决方案板对板连接器板对板连接器

对参数有疑问？问 AI 助手

商业参数

零件号别名	54745226287 JE150318747	产品类别	Headers & Wire Housings
标准包装数量	Bulk	工厂包装数量	100

合规参数

RoHS	Lead free / RoHS Compliant	海关税号	85369010
材料阻燃等级	:UL94V-0

电气参数

额定电压	1 kV	工作电压	:350V
最大额定电流	1A	绝缘电阻	:1000Mohm

机械参数

颜色	Gray	间距	2.54 mm
重量	0.004	包装方式	Bulk
方向	straight	排间距	0.100" (2.54mm)
端接方式	Solder	触头类型	Female Socket
引脚间距	:2.54mm	柱间距	2.54mm
安装类型	Through Hole	连接器类型	Receptacle
接触镀层	Gold Over Nickel	排数	2
触头材料	Copper Alloy	壳体材料	Polyester
包装数量	100	连接器 - 电缆	socket
端接样式	Through Hole	第一触头极性	Socket (Female)
连接器颜色	:Grey	触点数	20
接触件端接	:Through Hole Vertical	位数	20
接触镀层厚度	12µin (0.30µm)	触点材料 - 镀层	gold plated
第一连接器安装特征	2x10

产品信息

SPG	100	类型	Socket Strip
连接器性别	SKT	系列	8500
产品特性	Polarizing Key	极性	:Bump
CAD图纸	3D CAD Model	产品子类型	Receptacles / Sockets - PCB
单元数量	1	加载位置数	All

环境参数

插拔次数

:200

工作温度

:105°C

文档与媒体

在线文档

mediawebserver.dyn?6666660Zjcf6lVs6EVs666UCJCOrrrrQ-

PDF 文档

1391444.pdf
