点击放大查看

9037440000

制造商	Weidmüller Holding AG & Co. KG
描述	Connector Accessories Wire End Ferrule With Plastic Collars Red FERRULE H1 0/15D ZH R FERRULE, TWIN ENTRY, 1.05MM Bootlace ferrule; insulated, double; copper; 1mm2; 8mm; tinned
分类	光电子学LED照明LED照明模块

商业参数

标准包装数量

Bag

合规参数

RoHS	Not applicable / Not applicable	SVHC	:No SVHC (20-Jun-2013)
海关税号	85369010

电气参数

驱动类型

bootlace ferrule

位数

8mm

机械参数

尺寸	Two x 17 AWG (1.00mm²)	颜色	Red
长度	:16mm	重量	0.016
绝缘类型	Insulated	导线线规	:1.0mm²
端接方式	:Crimp	引脚长度（针脚）	8.00mm
引脚直径	:2.2mm	安装类型	crimped
螺柱/焊片尺寸	:8mm x 2mm	连接器类型	:Ferrule
接触镀层	:Tin	安装样式	for cable
触头材料	:Copper	套圈材料	insulated, double
绝缘颜色	:Red	总长度	15.00mm
包装数量	500	连接器颜色	:Red
绝缘材料 - 材质	:Plastic	线规或范围 - AWG	:17AWG
线规或范围 - mm²	:1mm²	触点材料 - 镀层	tinned

产品信息

SPG	500	类型	Wire End Ferrule
样式	DIN	系列	:-
单元数量	1	射频系列/标准	9037440000

环境参数

工作温度

105°C

文档与媒体

PDF 文档

27478.pdf
