1651520000
| 制造商 | Weidmüller Holding AG & Co. KG |
| 描述 | Contact PIN Crimp ST Cable Mount HDC-C-HD-SM0.14-0.37AG 100/PK |
| 分类 |
商业参数
| 其他名称 | HDC-C-HD-SM0.14-0.37AG 100/PK | 标准包装数量 | Bag |
合规参数
| RoHS | Lead free / RoHS Compliant | IEC标准 | 27-44-02-04 |
| 标准编号 | 30-21-18-01 | ||
电气参数
| 频率 | 27-44-02-04 | 插入损耗 | HD, HDD, HQ, MixMate, CM 10, CM BUS (CSB) |
| 体积电阻 | ≤ 4mΩ | 最小磁芯截面积 (Amin) mm² | 0.14 mm² |
机械参数
| 重量 | 0.6 g | 直径 | 3.5 mm |
| 材料（通用） | Copper alloy | 包装方式 | Bulk |
| 导线线规 | 22-26 AWG | 端接方式 | Crimp |
| 芯径 | 1.6 mm | 插针或插孔 | Pin |
| 电缆直径 | 0.37 mm² | 连接器类型 | Connector Rectangular |
| 接触镀层 | Silver | 触头材料 | Copper Alloy |
| 剥线长度（范围） | 8 mm | 接触件端接 | Crimp |
| 宽度/横截面 | 0.14 - 0.37 mm² | 接触镀层厚度 | 118.1µin (3.00µm) |
产品信息
| 类型 | Machined | 连接器性别 | PIN |
| 系列 | HD | ETIM 6*0 | EC000796 |
| GTIN（EAN） | 4008190400194 | 描述 | For further accessories, see chapter J - tools, see chapter K |
| 工程数据 | EPLAN, Zuken E3.S | 固件版本 | Heavy Duty Connectors, Crimp contact, HD, HDD, HQ, MixMate, CM 10, CM BUS (CSB), Male, Conductor cross-section, max.: 0.37, turned, Copper alloy |
| 连接方式 | turned | ||
环境参数
| ET（伏秒积） | EC000796 | 防护等级 | 27-14-34-19 |
