点击放大查看
1003240000
| 制造商 | Weidmüller Holding AG & Co. KG |
| 描述 | SHIELD CLAMP |
商业参数
| 标准包装数量 | 100 | ||
合规参数
| RoHS | Conform | IEC标准 | 27-44-02-03 |
| 标准编号 | 30-21-18-01 | ||
电气参数
| 频率 | 27-44-02-05 | ||
机械参数
| 重量 | 0.43 g | ||
产品信息
| 类型 | HDC HE CP | ETIM 6*0 | EC000438 |
| GTIN（EAN） | 4032248698233 | 附件类型 | Coding Pin |
| 固件版本 | Heavy Duty Connectors, Accessories, Coding System | 适用产品/相关产品 | Rockstar® Inserts |
| 技术数据描述文本 | This coding pin can be used in all inserts where HE crimp contacts are used.On the socket side of the plug-in connector, individual contact chambers can hold a coding pin instead of a crimp contact – the opposite contact is left free. | ||
环境参数
| ET（伏秒积） | EC000438 | 防护等级 | 27-44-02-05 |
