M24308/2-286F
| 制造商 | TE Connectivity Ltd. |
| 描述 | CONN D-SUB RCPT HD 15P SER 90 Conn Housing RCP 15 POS Crimp ST Panel Mount |
| 分类 |
商业参数
| 标准包装数量 | 50 | ||
机械参数
| 包装方式 | Bulk | 触头类型 | Signal |
| 安装类型 | Free Hanging (In-Line) | 连接器类型 | Receptacle for Female Contacts |
| 法兰特征 | Housing/Shell (Unthreaded) | 排数 | 3 |
| 连接器样式 | D-Sub, High Density | 位数 | 15 |
| 外壳材料及表面处理 | Steel, Cadmium Plated | 外壳尺寸，连接器布局 | 1 (DE, E) High Density |
产品信息
| 备注 | Contacts Not Provided | ||
